4.6.4.2 Parameter Object (0F )
hex
The Parameter Object (Class Code 0F
the DA1 variable frequency drive's configuration data and parameters. It
contains an instance for each parameter, with the instance being linked to
the parameter to be configured.
Class Attributes
Attribute Attribute name
Id
1 Revision
2 Maximal Instance
8 Parameter Class
Descriptor
9 Configuration
Assembly
Instance
Instance attributes
Attribute Attribute name
Id
1 Parameter Value
2 Link Path Size
3 Link Path
4 Descriptor
5 Data Type
6 Data Size
7 Parameter Name
String
8 Units String
DX-NET-DEVICENET 02/14 MN04012005ZEN www.eaton.com
) serves as a DeviceNet interface to
hex
Access Data type
right
ro | rw
ro UINT
ro UINT
ro WORD
ro UINT
Access Data type
right
ro | rw
ro/rw Defined using
attributes 4, 5,
6.
ro USINT
ro Packed EPATH
ro WORD
ro EPATH
ro USINT
ro SHORT_STRING
ro SHORT_STRING
