3 Installation
3.5 Mounting from frame size FS4
20
After doing so, you can insert the connection on the right-hand side and use
the screws to secure it.
Then put the cover back on and use the two screws (turn them 90°) to
secure it.
2
T 8
0.25 Nm
(2.21 lb-in)
Figure 11:Inserting the fieldbus connection
