4 Commissioning
4.6 Supported objects
34
Attribute Attribute name
Id
13 Produced Connection Path
Length
14 Produced Connection Path
15 Consumed Connection
Path Length
16 Consumed Connection
Path
17 Production Inhibit Time
18 Connection Timeout
Multiplier
Polled I/O connection
When a polled I/O connection is used, a conventional master/slave
relationship is established between a controller and a DeviceNet device.
Polled I/O connections are point-to-point connections between two nodes on
the bus. When using this type of connection, the master sends a poll request
to the slave, which in turn responds with a poll response.
Table 8: Instance 2: Polled I/O connection
Attribute Attribute name
Id
1 State
2 Instance Type
3 Transport Class Trigger
4 Produced Connection ID
5 Consumed Connection ID
6 Initial Communication
Characteristics
7 Produced Connection Size
DX-NET-DEVICENET 02/14 MN04012005ZEN www.eaton.com
Access Data type
right
ro | rw
ro UINT
ro EPATH
ro UINT
ro EPATH
ro UINT
ro/rw UINT
Access Data type
right
ro | rw
ro USINT
ro USINT
ro Byte
ro UINT
ro UINT
ro Byte
ro UINT
Description
Minimum time between two
instances of data
Description
Connection status.
0: Non existent
1: Configuring
2: Waiting for connection ID
3: Established
4: Time out
0001 (I/O Connection)
hex
Type of connection:
82 : Server, Polled Class2
hex
80 : Server, COS/Cyclic,
hex
Class 0, No Ack.
FFF : Note consuming
hex
(COS/Cyclic)
Other: CAN ID for transmission
01 : Polled
hex
F1 : COS/Cyclic, No Ack.
hex
01 : COS/COS/cyclic, Ack.
hex
The maximum number of bytes
that will be sent
0000 : COS/Cyclic
hex
others: Size of Write Process
Data (Polled)
