4 Commissioning
4.6 Supported objects
36
Bit-Strobe I/O Connection
Bit-strobe I/O connections are connections between a DeviceNet client and
an unspecified number of servers. When using this type of connection, the
client broadcasts a command requiring a response from the servers.
Table 9: Instance 3: Bit-strobe I/O connection
Attribute Attribute name
Id
1 State
2 Instance Type
3 Transport Class Trigger
4 Produced Connection ID
5 Consumed Connection ID
6 Initial Communication
Characteristics
7 Produced Connection Size
8 Consumed Connection Size
9 Expected Packet Rate
12 Watchdog Timeout Action
13 Produced Connection Path
Length
14 Produced Connection Path
15 Consumed Connection
Path Length
16 Consumed Connection
Path
17 Production Inhibit Time
18 Connection Timeout
Multiplier
DX-NET-DEVICENET 02/14 MN04012005ZEN www.eaton.com
Access Data type
right
ro | rw
ro USINT
ro USINT
ro Byte
ro UINT
ro UINT
ro Byte
ro UINT
ro UINT
ro/rw UINT
ro/rw USINT
ro UINT
ro EPATH
ro UINT
ro EPATH
ro UINT
ro/rw UINT
Description
Connection status.
0: Non existent
1: Configuring
2: Waiting for connection ID
3: Established
4: Time out
5: Deferred
0001 (I/O Connection)
hex
Type of connection:
82h: Transport Class & Trigger
Server, Cyclic, Class 2
–
–
Produced using message
group 1 and consumed using
message group 2
The maximum number of bytes
that will be sent (8 bytes)
0008
hex
–
0000
hex
(Transition to the timed out
state)
0007
hex
20 04 25 nn nn 30 03
hex
0000
hex
20 04 25 nn nn 30 03
hex
0000
hex
0000
hex
