Phoenix Model PH059 Instruction Manual page 8

Instruction Manual
Drill
3. Using a modeling knife, carefully cut out two line
from the margin of the hole onto the wheel pant.
Just cut only one side of the wheel pant, where
the main gear will install. Be sure to make a left
and right wheel pant.
4. Slide a 4.5mm nut/ two 16mm flat washers /
4.5mm nut / collar / wheel / collar onto the axle.
5. Slide the axle assembly into the wheel pant.
There are just one nut and two flat washers
!
outside of the wheel pant.
6. Remove one nut, one flat washer. Attach the
main landing gear to the axle.
7. Center both collars and wheel in the middle of
the wheel pant, lock both collars in place using
a hexagon 2mm screw.
16mm flat washer
Cut
29
30
7
CESSNA 182
After installing the wheel pant, apply a small
!
drop of thin C/A to the bottom nut.
9. Repeat step # 1-8 to install the second wheel
pant assembly.
MAIN GEAR INSTALLATION
INSTALLING THE MAIN LANDING GEAR
1. Four nuts have been installed at the factory.
2. Install main landing gear into the fuselage using
(4) 4mm x 20mm machine screws and 16mm
flat washers provided in the kit.
Screw
Remove the covering
31
Screw
32
Secure the
gear cover
33
