Changing Settings - Inkbird ITC-306A Manual

6.3 Changing Settings

Code Symbol
TS1 TS1
TS2 TS2
AH AH
AL AL
CT CT
CA CA
CF CF
6.4 Control Function Description
When the controller is working normally, the controller will automatically
select the smaller temperature value of the two settings TS1 and TS2 to start
the heating, and will stop heating when the temperature reach the larger one
(the minimum absolute value of TS1 and TS2 is 0.3 °C or 0.5°F), PV displays
the current temperature measurement value, and the SV displays the
temperature at which heating stops.
6.5 （ AH,AL） High/Low Temperature Alarm
When measured temperature ≥the setting value of high temperature AH, it will
alarm and turn off heating output. The screen will rotate to display"AH"and
current temperature, buzzer will "bi-bi-Biii", until the temperature < AH, buzzer
will be off and return to normal display and control. Or press any button to
only turn the buzzer alarm off.
When measured temperature ≤ the setting value of low temperature AL, it will
alarm. The screen will rotate to display"AL"and current temperature, buzzer will
"bi-bi-Biii", until the temperature > AL, buzzer will be off and return to normal
display and control. Or press any button to only turn the buzzer alarm off.
High and low temperature alarm will be pushed to mobile APP and remind
the customer that the product is in alarm state.
6.6
Continuous
Heating
Time
Alarm(CT)
When measured temperature ≤ the starting heating temperature, the output
Menu Function
Temperature Setting 1
Temperature Setting 2
High Temperature
Alarm
Low Temperature
Alarm
Continuous Heating
Time
Temperature
Calibration
Fahrenheit or Celsius
Setting
Setting Range
20.0℃~35.0℃
68.0℉~95.0℉
20.0℃~35.0℃
68.0℉~95.0℉
0.0℃~100℃
32.0℉~212℉
0.0℃~100℃
32.0℉~212℉
1~72 Hour
-9.9℃~9.9℃
-15.0℉~15.0℉
C or F
Default
Settings Remarks
25.0℃
77.0℉
26.0℃
78.0℉
100℃
212℉
0.0℃
32.0℉
6 Hours
0.0℃
0.0℉
F
