1 Drawer Entertainment Unit
Assembly Instructions
033 xx 3042
- Please keep for future reference
Dimensions
Width - 101.6cm
Depth - 38.8cm
Height - 34.4cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 08/10/2012
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 033 3042 Series
Summary of Contents for Argos 033 3042 Series
- Page 1 1 Drawer Entertainment Unit Assembly Instructions 033 xx 3042 - Please keep for future reference Dimensions Width - 101.6cm Depth - 38.8cm Height - 34.4cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 8803 8800 8802 8801 Bottom (101.6x38.8cm) (91x36cm) Right End Panel Left End Panel (32.2x38.2cm) (32.2x38.2cm) 8806 Plinth (91x76cm) 8807 Backpanel (45.6x22.8cm) 8804 8805 Division...
- Page 4 If you have damaged or missing components, call the Components-Fittings Customer Helpline: 0845 0613967 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
-
Page 5: Exploded View
Exploded View Please check you have all the fittings listed below 8800 8802 8804 8807 8801 8803 8806 622xx7000 624xx7006 4472 8805 623xx7000... - Page 6 Assembly Instructions Fittings you will need for this step: Step 1 Fitting dowels to top panel. 8800 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Step 2 Fittings you will need for this step: Fitting cams to the bottom panel.
- Page 7 Assembly Instructions Step 4 Fitting cams & dowels to the divider. 8804 Note: Ensure cam arrow points towards the edge with hole. Step 5 Attaching runners to right end and divider Position the runner so that the second hole 8804 8803 from the front of the runner lines up with the...
- Page 8 Assembly Instructions Step 7 (x4) Drawer assembly Insert dowels into drawer front. Note: Insert metal dowels as far as 8805 shown by arrows. Do not over tighten. (x4) Right hand side 623xx7000 Insert small cams 622xx7000 into left and right 623xx7000 drawer sides.
- Page 9 Assembly Instructions Step 7 - Continued Drawer assembly 624xx7006 Continued... 622xx7000 Slide drawer bottom into grooves in the left and right drawer sides and the drawer back. 4472 Foil Face Ensure foil on the drawer bottom is facing upwards. 623xx7000 SLIDE! : Locate the metal dowels (already inserted)
- Page 10 Assembly Instructions Step 9 Attach bottom and plinth to right end. Connect the cams in the bottom panel 8801 plinth panel 8806 to the 8801 right hand end panel Ensure plinth sits 8803 flush. 8806 8803 Ensure plinth is not overhanging. CAUTION! An additional person will be required to hold...
- Page 11 Assembly Instructions Step 11 Attach the division Line the wooden dowels already inserted in the 8804 division panel with the center holes in the bottom panel. 8804 Fix with screws Step 12 Attaching the trims Locate the notch on the trim into the grooves in the end panels.
- Page 12 Assembly Instructions Step 13 Slide in backpanel Slide the back panel into the grooves in the division and right hand end panel. SLIDE! 8807 8804 8803 Step 14 Attach top panel Connect the dowels in the top panel to the cams in the end panels and the 8800 division panel.
- Page 13 Assembly Instructions Step 15 (x2) Locate drawers For this step we recommend you follow the helpful hints page. 2nd HOLE...
- Page 14 Assembly Instructions Step 26 Locate drawers helpful hints Pull sliding part of drawer runners so they are fully extended. Locate drawer onto runners. Locate screwdriver into second threaded hole in drawer runner Keeping screwdriver in place push the drawer closed.The screwdriver will push against the end panel and extend the 2nd hole...
- Page 15 Assembly Instructions Congratulations! Your unit is complete. Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 0845 061 3967 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
