Mia 3 Drawer Chest
Assembly Instructions -
Dimensions
:
Width
52.5 cm
Depth
:
43.3 cm
:
60.5 cm
Height
Assembly Instructions -
If you need help or have damaged or missing parts, call the Argos Customer Helpline: 0845 640 30 30
350270
Please keep for future reference
Please keep for future reference
White 2587136
Issue 1 - 25-05-2014
Advertisement
Related Manuals for Argos Mia 3 Drawer Chest
Summary of Contents for Argos Mia 3 Drawer Chest
- Page 1 52.5 cm Depth 43.3 cm 60.5 cm Height Assembly Instructions - Please keep for future reference If you need help or have damaged or missing parts, call the Argos Customer Helpline: 0845 640 30 30 Issue 1 - 25-05-2014 350270...
- Page 2 ! Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on components and tools listed on the product, this could cause pages 2 and 3. damage.
- Page 3 Components - Panels If you have damaged or missing components, call the Argos Customer Helpline: 0845 640 30 30 Please check you have all the panels listed below (52,5 cm x 43,3 cm) Front rail (40,7 cm x 7 cm)
- Page 4 Components - Fittings Please check you have all the panels listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. ø7.8 x 40mm Wooden dowel x ø6 x 30mm Wooden dowel x 12 ø3 x 35mm Screw x ø15 x 10.5mm Cam x 12...
- Page 5 Assembly Instructions Step 1 Assembly of the chest. Step 1.1 Screw the bolts into ø5 x 8, cc34mm Bolt x 4 the holes indicated on the Step 1.2 Fix the posts onto the ø4 x 25mm Screw x sides using screws into the holes indicated.
- Page 6 Assembly Instructions Step 1.4 Slide the top of the ø5.8 x 8mm Screw x 12 245 x 17 x 10mm Drawer runner x drawer runners backwards. You can identify the front end of Hole no. 2 the drawer runner Front end the two M4 holes.
- Page 7 Assembly Instructions Step 1.6 Fix the angles using 44 x 23 x 23mm Angle x ø4,2 x 9,5mm Screw x screws into the holes indicated on the front rail Step 1.7 Knock the dowels into ø7.8 x 40mm Wooden dowel x the holes indicated on the back rail using a...
- Page 8 Assembly Instructions Step 1.10 Place the front rail ø4,2 x 9,5mm Screw x as shown. Fix the angles to the sides using screws See detail. Step 1.11 Distribute equally ! Place the back into 1.2 x 15mm Nail x the rabbet on the top and onto the posts Important! Make sure the...
- Page 9 Assembly Instructions Step 2 Assembly of the drawers. Step 2.1 Fix the drawer sides ø3 x 35mm Screw x to the drawer back shown, using screws Step 2.2 Knock the dowels ø6 x 30mm Wooden dowel x 12 into the holes indicated on the drawer sides using a smal hammer.
- Page 10 Assembly Instructions Step 2.5 Push the drawer fronts ø15 x 10.5mm Cam x 6 onto the drawer sides Place cams into the holes indicated. Arrow pointing towards the front. Turn the cams to the right to fix the fronts. Step 2.6 Important! Back fitting w.
