Costello TV Bed
Assembly Instructions - Please keep for future reference
Dimensions (4-6)
Length - 219
cm
Width - 145.5 cm
Height - 115.5 cm
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call one of the Customer Helplines:
0345 6400 800 (For order problems,incorrect product or missing/damaged parts).
01626 879 158 (Only for problems with TV Installation, Electrical System or TV Lift not working).
Dimensions (5-0)
Length - 227
cm
Width - 160.5 cm
Height - 115.5 cm
0504/8036
0464/5643
Issue 1 -09/10/15
Advertisement
Related Manuals for Argos Costello 0504/8036
Summary of Contents for Argos Costello 0504/8036
- Page 1 Costello TV Bed 0504/8036 Assembly Instructions - Please keep for future reference 0464/5643 Dimensions (4-6) Dimensions (5-0) Length - 219 Length - 227 Width - 160.5 cm Width - 145.5 cm Height - 115.5 cm Height - 115.5 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call one of the Customer Helplines: 0345 6400 800 (For order problems,incorrect product or missing/damaged parts).
- Page 2 Safety and Care Advice Check you have all the Assemble the item as close We do not recommend the components and tools listed on to its final position (in the same use of power pages 2 and 3. room) as possible. drill/drivers for Remove all fittings from the Assemble on a soft level...
- Page 3 0345 6400 800 (4-6-1455 × 1155mm) (4-6 -1455 × 820mm) Headboard Footboard (5-0 -1605 × 820mm) (5-0 -1605 × 1155mm) Right side rail (4-6 -1930 × 350 x 35mm) (5-0 -2010 × 350 x 35mm) (4-6 -1930 × 350 x 35mm) Left side rail (5-0 -2010 ×...
- Page 4 Components - Fittings 0345 6400 800 Allen screw (M8x30mm) Allen screw (M8x20mm) Spring Washer (for M8 screws) Flat Washer (for M8 screws) Allen Key (for M8 screws) Cable Clip Cable Tie TV INSTALLATION KIT Allen Key (5mm) Screw-Washer sets (M8x25mm) Spanner (for 9mm Domed Nut) Allen Key (4mm) Counter-Sunk Screws (M6x12mm)
- Page 5 Assembly Instructions Assembling Support Legs a: Fit support bar legs to central support using fixings...
- Page 6 Assembly Instructions a: Loosely insert two screws with spring washers and flat washers into each side of headboard and footboard 10mm Note: Do not tighten fully Leave 10mm protruding as in the diagram. b: Fit the side rails brackets onto screws , locating the brackets behind flat...
-
Page 7: Electrical & Cable Connections
Assembly Instructions TV Mounting Column Electrical & Cable Manual Raise & Lower Buttons. Connections a: Connect the Mains power lead into the 3 Pin socket located on the right-hand side at bottom of the footboard Connect UK plug to your wall socket. - Page 8 Assembly Instructions TV Installation a: Place TV on Platform as in sketch. Occasionally the remote control eye is mounted underneath the TV so please make sure it can be operated correctly. It may be necessary raise height of TV by using extra TV Mounting Column pads Note: TV Mounting Column...
- Page 9 Assembly Instructions Connect Leads a: Use cable clip Aerial Lead back of TV to keep leads tight - make sure all leads at rear of TV go into the ducts and cannot get 2.8 Mt HDMI trapped. Leads - x2 Note: Connect cables carefully.
- Page 10 Assembly Instructions Plug in TV Note: Power socket for the TV is not to be used for any other equipment because it is not a permanent supply, it cuts off power to the TV when it is down in the starting TV Power Lead supplied with your TV position.
