1 drawer low plasma unit

Advertisement

Quick Links

1 Drawer Low Plasma Unit
Assembly Instructions
033 xx 3562
- Please keep for future reference
Dimensions
Width - 141cm
Depth - 38.8cm
Height - 25cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 26/03/2013

Advertisement

loading
Need help?

Need help?

Do you have a question about the 033 3562 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos 033 3562 Series

  • Page 1 1 Drawer Low Plasma Unit Assembly Instructions 033 xx 3562 - Please keep for future reference Dimensions Width - 141cm Depth - 38.8cm Height - 25cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967 Please turn to back page for important information when contacting Customer Helpline.
  • Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
  • Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges Front Grooved edge Left division (14.5x34cm) Left side (23.5x35.8cm) Code - 9058 Code - 8302 Front Grooved edge Trim x 2 (23.5cm long) Right division (14.5x34cm)
  • Page 4: Components - Exploded View

    Components - Exploded View Important - Thick lines indicate finished edges 8300 8302 9058 8307 684006525 9059 Trim 622xx7002 8301 624xx7005 8303 623xx7002 4472 8306 8298 684006525 Trim...
  • Page 5 If you have damaged or missing components, call the Components-Fittings Customer Helpline: 0845 0613967 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
  • Page 6 Assembly Instructions Step 1 Fittings you will need for this step: Fitting dowels to top panel (x8) 8300 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Step 2 Fitting cams to plinth Fittings you will need for this step: and bottom panel Large (x8)
  • Page 7 Assembly Instructions Step 3 Fittings you will need for this step: Fitting cams and Large dowels to left and Front grooved edge (x4) right hand end panels (x8) Note: Ensure cam 8302 arrow points towards the edge with hole. 8303 Note: Insert metal dowels as far as...
  • Page 8 Assembly Instructions Step 5 Fittings you will need for this step: Attaching runners (x2) (x1) : Align the drawer runner with the edge of panel 9158 , the 2nd hole from the front will then line up with a pre-drilled hole, secure the runner to the Note: panel using screws...
  • Page 9 Assembly Instructions Step 7 Fittings you will need for this step: Attaching runners (x1) (x2) : Align the drawer runner with the edge of panel Note: 9159 , the 2nd hole from Ensure these the front will then line up holes are with a pre-drilled hole, positioned as shown.
  • Page 10 Assembly Instructions Step 9 Fittings you will need for this step: Drawer assembly (x2) Insert dowels into 8306 drawer front 8306 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Fittings you will need for this step: Small Right hand side (x2)
  • Page 11 Assembly Instructions Step 9 - Continued Drawer assembly Continued... Slide drawer bottom 4472 into grooves in left,right drawer sides 4472 and drawer back. Ensure foil on the FOIL FACE drawer bottom is facing upwards. : Insert cams already inserted in left and right drawer sides onto dowels in drawer...
  • Page 12 Assembly Instructions Step 10 Fittings you will need for this step: Attach lh & rh divisions to backpanel (x4) Locate screws through holes in lh divider panel 9158 9158 rh divider panel 9159 8307 and screw into holes in 8307 backpanel 9159 Ensure panels sit...
  • Page 13 Assembly Instructions Step 12 Front grooved edge Attach bottom to left hand end panel 8302 Insert dowels in lh end panel 8302 2 into cams in bottom panel 8301 Then lock. 8301 Turn cam 180 degrees to lock Step 13 Attach plinth to left hand end panel then 8302...
  • Page 14 Assembly Instructions Step 14 8302 Attach top to ends Locate dowels top 7 8300 into cams in left , right 8303 8302 hand end panels. 8300 Then lock. Turn cam 180 degrees 8303 to lock Step 15 Fittings you will need for this step: Attach silver trim Silver Trims (x2)
  • Page 15 Assembly Instructions Step 16 Fittings you will need for this step: Attach bottom panel to lh and rh divider panels (x4) Locate screws through holes in bottom panel and screw 8301 9158 9158 into lh divider 9159 rh divider 9159 8301 Step 17 Fittings you will need for this step:...
  • Page 16 Assembly Instructions Step 17 - continued Locate drawers helpful hints Pull sliding part of drawer runners so they are fully extended. Locate drawer onto runners. Locate screwdriver into second threaded hole in drawer runner Keeping screwdriver in place push the drawer closed.The screwdriver will push against division panel and extend the...
  • Page 17 Congratulations! your unit is complete. Note: Please turn over for important information.
  • Page 18 Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967 Simply contact us on CUSTOMER HELPLINE : 0845 0613967 Between 8am - 4.30pm Monday to Thursday and 8am - 2.30p.m friday. Your statutory rights are not affected. Please have the following information: Unit Description, Product Code, Product Colour, Place of Purchase, Catalogue Ref.
  • Page 19 Notes...
  • Page 20 Notes...
