2 Door Cupboard
Assembly Instructions
044 xx 0502
- Please keep for future reference
Dimensions
Width - 66.8cm
Depth - 34.8cm
Height - 72cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967
Please turn to back page for important information when contacting Customer Helpline.
Rev B - 30.09.10
PDF processed with CutePDF evaluation edition
www.CutePDF.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos 044 0502 Series
Summary of Contents for Argos 044 0502 Series
- Page 1 2 Door Cupboard Assembly Instructions 044 xx 0502 - Please keep for future reference Dimensions Width - 66.8cm Depth - 34.8cm Height - 72cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967 Please turn to back page for important information when contacting Customer Helpline.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
- Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges Door x 2 Left hand end Right hand end (66x33cm) (66x33cm) (65.4x32.9cm) Code - 7530 Code - 7531 Code - 7533 Bottom (66.8x34.8cm) (66.8x34.8cm)
-
Page 4: Components - Exploded View
Components - Exploded View Important - Thick lines indicate finished edges 7528 7534 7530 7533 7532 7531 7533 7529... - Page 5 If you have damaged or missing components, call the Components-Fittings Customer Helpline: 0845 0613967 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
- Page 6 Assembly Instructions Step 1 Fittings you will need for this step: Fitting dowels to top panel (x4) Note: Insert metal dowels as far as shown by arrows. 7528 Do not over tighten. Fittings you will need for this step: Step 2 Fitting cams to Large shelf...
- Page 7 Assembly Instructions Step 3 Fittings you will need for this step: Fitting cams, metal Large dowels and wooden dowels to left end (x2) (x2) (x2) 7530 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Use a hammer to knock in wooden dowels into inner holes.
- Page 8 Assembly Instructions Step 5 Fittings you will need for this step: Fitting cams, metal Large dowels and wooden dowels to right end (x2) (x2) (x2) Note: Insert metal 7531 dowels as far as shown by arrows. Do not over tighten. Use a hammer to knock in wooden dowels into inner holes.
- Page 9 Assembly Instructions Step 7 Fittings you will need for this step: Attach hinges and handles to doors (x2) (x4) (x8) (x4) Important: Insert hinges into holes, ensure the hinge is straight (90 degree angle). 7533 x 2 Before securing the 7533 x 2 hinges , we recommend...
- Page 10 Assembly Instructions Step 8 Attach left hand and right hand panels to shelf Note: Ensure the shelf is positioned correctly with cam fittings to Insert dowels in left this side. 7530 and right 7531 end panels into cams in shelf 7532 7531 Then lock.
- Page 11 Assembly Instructions Step 10 Locate backpanel into grooves in left and right hand end panels and top panel 7534 7531 Important: 2 people required 7534 Locate backpanel into grooves in left hand 7530 and right hand 7530 7531 . Ensure the backpanel goes into 7528 groove in top...
- Page 12 Assembly Instructions Fittings you will need for this step: Step 12 Attach glide feet To locate feet to the bottom you will 7529 (x4) (x4) need to mark position with a bradawl 30mm in as shown, then screw the foot into place. Repeat in each corner.
- Page 13 Assembly Instructions Step 13 Hanging doors With help, slot door hinges onto hinge plates Ensure screw on hinge slides into the slot on hingeplate See Diagrams 1,2 and 3. 7533 Tighten screw shown to lock hinges in position. Repeat a and b on remaining door.
- Page 14 Assembly Instructions Step 14 Hinge adjustment To move doors up or down: loosen screws shown and move doors to suit. Re-tighten screws. To move doors in or out: loosen screw shown and move doors to suit. Re-tighten screws. To move doors left or right: loosen screw shown and move doors to suit.
- Page 15 Congratulations! your unit is complete. Note: Please turn over for important information.
- Page 16 Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967 Simply contact us on CUSTOMER HELPLINE : 0845 0613967 Between 8am - 4.30pm Monday to Thursday and 8am - 2.30p.m friday. Your statutory rights are not affected. Please have the following information: Unit Description, Product Code, Product Colour, Place of Purchase, Catalogue Ref.
