Tolga 03R
Assembly Instructions
Dimensions
Width - 112,5cm
Depth - 51,75cm
Height - 180cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 03456 400 800
- Please keep for future reference
462/6071
OAK
482/6369
PINK
496/5581
BLUE
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
462/6071
482/6369
496/5581
Issue: 3 - 18/05/16

Advertisement

loading
Need help?

Need help?

Do you have a question about the Tolga 03R 462/6071 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Tolga 03R 462/6071

  • Page 1 482/6369 PINK 496/5581 BLUE Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 03456 400 800 Issue: 3 - 18/05/16...
  • Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce components and tools listed or put weight on the product, the likelihood of on the following pages.
  • Page 3 Components - Panels If you have damaged or missing components, 03456 400 800 call the Customer Helpline: Please check you have all the panels listed below Top x1 (1095 x 496 x 18mm) P1012 Back Broad x1 (1723 x 741 x 2,5mm) BO2579 Shelf Broad x1...
  • Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. FA1510 FA1515 FK1005 Glue x 1 Nail x 60 Confirmat screw x 4 (5x40mm)
  • Page 5 Assembly Instructions Step - 1 Insert locking nuts E into shelfs 3. Make sure the ‘arrow’ on locking nuts E points towards the hole in the edge of 3. Repeat with panels: 4, 5, 6. Step - 2 Screw locking screw D into left side 9.
  • Page 6 Assembly Instructions Step - 3 Screw locking screw D into right side 7. Note: Insert locking screw D as far as shown. Do not over tighten. Attach hanger rail support H using 15mm screw M onto right side 7. Finished Note: Use the lower two front edge holes to mount hanger...
  • Page 7 Assembly Instructions Step - 4 Put drop of glue A into the 4 holes of plinth #. Put dowels O into the holes of plinth #. Step - 5 Attaching panels Position Top panel 3 onto mid panel 8. Insert two confirmat screws C through top panel 3 into mid panel 8 as shown.
  • Page 8 Assembly Instructions Step - 7 Attaching panels Position right side 2 onto the unit. Use a screwdriver to turn locking nuts E clockwise to lock. Finished front edge Step - 8 Attaching panels Position Plinth @ onto the unit as shown. Position left side 9 onto the unit.
  • Page 9 Assembly Instructions Step - 9 Fitting back panel Attach back 1,2 to the back with the coloured surface facing the inside using nails B. Use nail holder P to hold the nails B vertical and at correct distance as you secure the back 1,2. Nails B should be spaced about 150mm apart.
  • Page 10 Assembly Instructions Step - 11 Inserting hanger rail Insert hanger rail large V into hanger rail support H. Insert hanger rail U into hanger rail support H Step - 12 Hanging doors With help, slot hinge door R onto hinge back Q. Tighten screw shown to lock hinges in position.
  • Page 11 Assembly Instructions Step - 13 Fixing to wall It is recommended that a wall. Position L-Bracket J onto top 3 as shown, fix by using 15mm screw N. Note: there are no pre-drilled holes for 15mm screw N. With help, move wardrobe into position.
  • Page 12 A Guide to - Hinge instructions Assemble Hinge back Hinge door a: Hook hinge door correctly to the hinge back as shown. b: Tighten screw to lock hinges in position. Note: The nick screw of hinge door should slide into the recess of hinge back.
  • Page 13: A Guide To - Wall Mounting & Fixings

    A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are suitable for supporting your unit.
