1 Drawer Display Unit Assembly Instructions 042 xx 3048 - Please keep for future reference Dimensions Width - 74.0cm Depth - 35.8cm Height - 161.7cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967 01709 534123 Please turn to back page for important information when contacting Customer Helpline.
Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
Page 3
Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges 8828 8829 Bottom x5 (74x35.8cm) (63.4x31cm) 8553 Plinth (63.4x76cm) 5671 Drawer Bottom (61.2x29.8cm) 622xx7002 8831 8830 Left drawer side Right End Panel Left End Panel (30x10cm) (159.5x35.2cm)
Page 4
If you have damaged or missing components, call the Components-Fittings Customer Helpline: 0845 0613967 01709 534123 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
Exploded View Please check you have all the fittings listed below 8828 8830 8832 8829 8831 684xx3048 622xx7002 8553 624xx7010 684xx3048 5671 8581 623xx7002...
Page 6
Assembly Instructions Fittings you will need for this step: Step 1 Fitting dowels to top panel. 8828 Note: Insert metal dowels as far as shown by arrows. Do not over tighten. Step 2 Fittings you will need for this step: Fitting cams to the bottom panels x5.
Page 7
Assembly Instructions Step 4 Fitting cams & dowels to the end panels. 8831 Note: Ensure cam arrow points towards the edge with hole. 8830 Step 5 Attaching runners to end panels Position the runner so that the second hole from the front of the runner lines up with the 8830 pre-drilled hole nearest...
Page 8
Assembly Instructions Step 6 (x2) Drawer assembly Insert dowels into drawer front. Note: Insert metal 8581 dowels as far as shown by arrows. Do not over tighten. (x2) Right hand side 623xx7002 Insert small cams 622xx7002 into left and right 623xx7002 drawer sides.
Page 9
Assembly Instructions Step 6 - Continued Drawer assembly 624xx7010 Continued... 622xx7002 Slide drawer bottom into grooves in the left and right drawer sides and the drawer back. 7010 Ensure foil on the drawer bottom is facing SLIDE! upwards. 623xx7002 Plain chipboard surface to underside.
Page 10
Assembly Instructions Step 7 Connect right hand and and top panel. Attach the top panel 8828 to the right end panel 8831 8828 8831 Note: You may need a small screwdriver. Step 8 Connect right hand end with bottom panels x5 and plinth. Connect the right end panel to the 5 x...
Page 11
Assembly Instructions Step 9 Connect the left hand end panel. Connect the dowels in the left end panel 8830 in order from the top into the bottom panels 8829 and finally the 8829 plinth panel 8553 8829 8829 8830 8553 8829 Step 10 Slide in back panel...
Page 12
Assembly Instructions Step 11 Insert back panel. Ensure that the back panel sits firmly inside all of the grooves before laying the unit back down to secure the bottom panel. 8832 Step 12 Secure the back panel. Slide the back panel into the grooves.
Page 13
Assembly Instructions Step 13 Turn unit over to attach the trims Locate the notch on the trim into the grooves in the end panels. 8830 To insert trims use a hammer, place a cardboard packing piece between the hammer and trims to protect the trims.
Page 14
Assembly Instructions Step 14 (x2) Stand unit upright to insert drawers. For this step we recommend you follow the helpful hints page. 2nd HOLE...
Page 15
Assembly Instructions Step 16 Locate drawers helpful hints Pull sliding part of drawer runners so they are fully extended. Locate drawer onto runners. Locate screwdriver into second threaded hole in drawer runner Keeping screwdriver in place push the drawer closed.The screwdriver will push against the end panel and extend the 2nd hole...
Page 16
Assembly Instructions Step 16 Fixing to wall We recommend that this unit is fixed to a suitable wall to prevent possible overbalancing. We have included a fixing bracket for this. No fixing screws are provided as they will need to suit the wall type, and the length of screw will depend on the distance from the...
Page 17
Congratulations! Your unit is complete. Assembly Instructions Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 0845 061 3967 01709 534123 8am - 4.30pm (Monday to Thursday) 8am - 2.30pm (Fridays) (by contacting the customer service line your statutory rights are not affected) Please have the following information to hand: >>...
