TV Unit
Assembly Instructions
033 xx 0501
- Please keep for future reference
Dimensions
Width - 89cm
Depth - 38.8cm
Height - 43cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967
Please turn to back page for important information when contacting Customer Helpline.
Rev A - 12.05.10
PDF processed with CutePDF evaluation edition
www.CutePDF.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 033 0501 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Argos 033 0501 Series

  • Page 1 TV Unit Assembly Instructions 033 xx 0501 - Please keep for future reference Dimensions Width - 89cm Depth - 38.8cm Height - 43cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967 Please turn to back page for important information when contacting Customer Helpline.
  • Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Do not stand or put weight on Check you have all the We do not the product, this could cause components and tools listed on recommend the damage.
  • Page 3 Components - Panels Please check you have all the panels listed below Important - Thick lines indicate finished edges Left hand end Right side (37x37cm) Right hand end (37x37cm) (37x37cm) Code - 7519 Code - 7524 Code - 7520 Bottom (89x38.8cm) (89x38.8cm) Code -...
  • Page 4: Components - Exploded View

    Components - Exploded View Important - Thick lines indicate finished edges 7527 7521 7519 7526 7524 7523 7525 7520 7522...
  • Page 5 If you have damaged or missing components, call the Components-Fittings Customer Helpline: 0845 0613967 Please turn to back page for important information when contacting Customer Helpline. Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly, In some case more fittings may be supplied than are required.
  • Page 6 Assembly Instructions Step 1 Fittings you will need for this step: Fitting dowels to top panel (x6) Note: Insert metal dowels as far as shown by arrows. Do not over tighten. 7521 Fittings you will need for this step: Step 2 Fitting cams to Large shelves...
  • Page 7 Assembly Instructions Step 3 Fittings you will need for this step: Fitting cams, metal Large dowels and wooden dowels to left and (x4) (x4) (x4) right hand ends Note: Insert metal 7519 dowels as far as shown by arrows. 7520 Do not over tighten.
  • Page 8 Assembly Instructions Step 5 Fittings you will need for this step: Fitting cams, metal Large dowels and wooden dowels to division (x2) (x2) (x2) Note: Insert metal dowels as far as 7524 shown by arrows. Do not over tighten. Use a hammer to knock in wooden dowels into inner holes.
  • Page 9 Assembly Instructions Step 7 Fittings you will need for this step: Attach hinges and handles to door (x1) (x2) (x4) (x2) Important: Insert hinges into holes, ensure the hinge is straight (90 degree angle). 7523 7523 Before securing the hinges , we recommend you pre - mark the doors using a bradawl.
  • Page 10 Assembly Instructions Step 8 Attach small shelf to left hand end and division Insert dowels in left Cam holes to 7519 into cams underside small shelf 7526 Then lock. Insert dowels 7524 7526 division 7524 into cams in small shelf 7526 7519 Then lock.
  • Page 11 Assembly Instructions Step 10 Attach top to left , right hand panels and division Warning: 7520 You may need help for this step. Locate cams in left 7519 , right 7520 division 7524 onto 7524 dowels in top panel 7521 Then lock.
  • Page 12 Assembly Instructions Fittings you will need for this step: Step 12 Secure bottom panel to left and right hand ends (x6) Locate wooden dowels already inserted in 7519 ends 7520 division 7524 into holes in bottom panel 7522 Now locate screw through holes in bottom 7520 7522...
  • Page 13 Assembly Instructions Step 14 Lift unit onto its feet to hang door With help, slot door hinges onto hinge plates Ensure screw on hinge slides into the slot 7523 on hingeplate See Diagrams 1,2 and 3. Tighten screw shown to lock hinges in position.
  • Page 14 Assembly Instructions Step 15 Hinge adjustment To move doors up or down: loosen screws shown and move doors to suit. Re-tighten screws. To move doors in or out: loosen screw shown and move doors to suit. Re-tighten screws. To move doors left or right: loosen screw shown and move doors to suit.
  • Page 15 Congratulations! your unit is complete. Note: Please turn over for important information.
  • Page 16 Important Information If you need help or have damaged or missing parts, call the Customer Helpline: 08450613967 Simply contact us on CUSTOMER HELPLINE : 0845 0613967 Between 8am - 4.30pm Monday to Thursday and 8am - 2.30p.m friday. Your statutory rights are not affected. Please have the following information: Unit Description, Product Code, Product Colour, Place of Purchase, Catalogue Ref.
