Establish the Network Connection

Incorrect laying of the connection cables can cause tripping.
Fractures, contusions and bruises can be the result.
➢ Place the connecting cables so that no one can trip over
them.
To establish the network connection, proceed as follows:
➢ Connect one plug of the enclosed network cable to the network
connector socket on the back of the scanner.
➢ Connect the second plug to the network socket of an existing network.

Connect the Optional Foot Switch

Incorrect laying of the connection cables can cause tripping.
Fractures, contusions and bruises can be the result.
➢ Place the connecting cables so that no one can trip over
them.
➢ Connect the plug of the foot switch to the connector socket for the foot
switch, located on the back of the scanner.
CAUTION
CAUTION
