- Page 1 Synway SMG Series SR Gateway Gateway SR500 Version 1.7.0 Synway Information Engineering Co., Ltd www.synway.net...
-
Page 2: Table Of Contents
Synway Information Engineering Co., Ltd Content Content ..............................i Copyright Declaration ........................... ii Revision History ........................... iii Chapter 1 Product Introduction ......................1 Typical Application ........................1 Feature List ..........................1 Hardware Description ......................2 Alarm Info ..........................3 Chapter 2 Quick Guide ......................... 5 Chapter 3 WEB Configuration ...................... -
Page 3: Copyright Declaration
Synway has made every effort to ensure the accuracy of this document but does not guarantee the absence of errors. Moreover, Synway assumes no responsibility in obtaining permission and authorization of any third party patent, copyright or product involved in relation to the use of this document. -
Page 4: Revision History
Synway Information Engineering Co., Ltd Revision History Version Date Comments Version 1.6.4 2016-10 Initial publication. Version 1.6.5 2017-06 New revision Version 1.7.0 2018-06 New revision Note: Please visit our website http://www.synway.net to obtain the latest version of this document. SR500 Gateway User Manual (Version 1.7.0) -
Page 5: Chapter 1 Product Introduction
Chapter 1 Product Introduction Thank you for choosing the Synway SR500 gateway products! Cooperating with the Synway SMG series digital gateways, the SR500 series call classification equipment, as a screen server, performs voice recognition on the called party of the digital gateway, analyzes the called status such as empty number, turnoff, out of operation, etc., and... -
Page 6: Hardware Description
Synway Information Engineering Co., Ltd Admin Authentication Support admin authentication to guarantee the resource and data security Maintain & Upgrade Description WEB Configuration Support of configurations through the WEB user interface Language Chinese, English Support of user interface, gateway service, kernel and firmware upgrades based... -
Page 7: Alarm Info
Synway Information Engineering Co., Ltd Type: RJ-45 Bandwidth: 10/100/1000Mbps Self-Adaptive Bandwidth Supported Auto MDI/MDIX Supported Amount: 1 Type: RS-232 Baud Rate: 115200 bps Connector: RJ45 (See Figure 1-5 for signal definition) Console Port Data Bits: 8 bits Stop Bit: 1 bit... - Page 8 Synway Information Engineering Co., Ltd Flash Device is running normally. Go out Device is working normally. Upon startup: Device is running normally. Alarm Indicator Light up In runtime: Device goes abnormal. Flash System is abnormal. Note: The startup process consists of two stages: System Booting and Gateway Service Startup.
-
Page 9: Chapter 2 Quick Guide
Synway Information Engineering Co., Ltd Chapter 2 Quick Guide This chapter is intended to help you grasp the basic operations of the SR500 gateway in the shortest time. Step 1: Confirm that your packing box contains all the following things. -
Page 10: Chapter 3 Web Configuration
Synway Information Engineering Co., Ltd Chapter 3 WEB Configuration 3.1 System Login Type the IP address into the browser and enter the login interface. See Figure 3-1. Figure 3-1 Login Interface The gateway only serves one user, whose original username and password are both „admin‟. You can change the username and the password via „System Tools ... -
Page 11: Warning Info
3.3.2 Authorization On the Authorization Management interface, you can import a trial or formal authorization just by uploading the authorization file which is provided by Synway and cannot be modified. SR500 supports up to 512 channels of authorization. 3.3.3 Management The table below explains the items shown on the Management Parameters Setting interface. -
Page 12: Ip Routing Table
Synway Information Engineering Co., Ltd The gateway will log out automatically if it is not operated during a time longer than Time to Log Out the value of this item, calculated by s, with the default value of 1800. Sets whether to enable the gateway to be accessed via SSH, with the default value of No. -
Page 13: Access Control
Synway Information Engineering Co., Ltd Click Modify to modify a routing. The configuration items on the routing table modification interface are the same as those on the Add Routing Table interface. Note that the item No. cannot be modified. To delete a routing, check the checkbox before the corresponding index and click the Delete button. -
Page 14: Ping Test
Synway Information Engineering Co., Ltd 3.3.8 PING Test Via the Ping Test interface, a Ping test can be initiated from the gateway on a designated IP address to check the connection status between them. The table below explains the configuration items shown on the interface. -
Page 15: Upgrade
Synway Information Engineering Co., Ltd 3.3.13 Upgrade On the upgrade interface, you can upgrade the WEB, gateway service, kernel and firmware to new versions. Select the upgrade package “*.tar.gz” via Browse… and click Update (The gateway will do MD5 verification before upgrading and will not start to upgrade until it passes the verification). -
Page 16: Appendix A Technical Specifications
Synway Information Engineering Co., Ltd Appendix A Technical Specifications Dimensions Power Requirements 440×44×267 mm Input power: 100~240V AC Weight Maximum power consumption: ≤22W Signaling & Protocol About 3.1 kg Environment SIP signaling: SIP V1.0/2.0, RFC3261 Audio Encoding & Decoding Operating temperature: 0 ℃... -
Page 17: Appendix B Troubleshooting
LAN1: 192.168.1.101 LAN2: 192.168.0.101 In what cases can I conclude that the SR500 gateway is abnormal and turn to Synway’s technicians for help? During runtime, the run indicator does not flash or the alarm indicator lights up or flashes, and such error still exists even after you restart the device or restore it to factory settings. -
Page 18: Appendix C Technical/Sales Support
Synway Information Engineering Co., Ltd Appendix C Technical/sales Support Thank you for choosing Synway. Please contact us should you have any inquiry regarding our products. We shall do our best to help you. Headquarters Synway Information Engineering Co., Ltd http://www.synway.net/ 9F, Synway D&R Center, No.3756, Nanhuan Road, Binjiang District,...
