SMG1002-2S VOIP Gateway
1.Appearance Description ................................................................................................................. 2
1.1 Front Panel ....................................................................................................................... 2
1.2 Rear Panel ........................................................................................................................ 2
2.Hardware Connection .................................................................................................................... 3
3.Basic WEB Settings .......................................................................................................................3
3.1 Network Setting ................................................................................................................. 4
3.2 Protocol And Number Setting ............................................................................................. 5
3.2.1 SIP Protocol And Number Setting ....................................................................................... 5
3.2.2 MGCP Protocol And Number Setting.................................................................................... 6
3.3 Call Route Setting .............................................................................................................. 6
4.Operation Test ............................................................................................................................. 7
Installation Manual
VER 1.5
Sywnay Information Engineering Co.,Ltd
www.synway.net
CONTENT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SMG1002-2S and is the answer not in the manual?

Questions and answers

Related Manuals for Synway SMG1002-2S

Summary of Contents for Synway SMG1002-2S

  • Page 1 SMG1002-2S VOIP Gateway Installation Manual VER 1.5 Sywnay Information Engineering Co.,Ltd www.synway.net CONTENT 1.Appearance Description ......................... 2 1.1 Front Panel ........................2 1.2 Rear Panel ........................2 2.Hardware Connection ........................3 3.Basic WEB Settings ........................3 3.1 Network Setting ......................... 4 3.2 Protocol And Number Setting .....................

  • Page 2: Appearance Description

    SMG1002-2S VOIP Gateway (SIP) Installation Manual VER 1.0 Appearance Description 1.1 Front Panel Image 1-1 Front Panel Indicator Description Power indicator, turn the lights connected to the power supply for the long Power bright state. Active Status indicators, the normal operation of the lamp is flashing...

  • Page 3: Hardware Connection

    Table 1-2 Rear panel connectors and LEDs Hardware Connection Firstly, using the power supplied in the package box to connect SMG1002-2S to power on it. And WAN port SMG1002-2S Series integrated access devices connected to the hub or switch, as shown in Figure 2-1.Making SMG1002-2S to connect with the service network, and then connecting the PC to the LAN port of SMG1002-2S, making data configuration for SMG1002-2S and Port1-2 connected to the phone.

  • Page 4: Network Setting

    3.1 Network Setting The WAN port of SMG1002-2S supports 3 different operating modes which are DHCP, PPPoE, and Static. Users can set “the WAN configuration” in the Web, such as IP address, mask, IP address, DSN and so on. Make...

  • Page 5: Protocol And Number Setting

    Usually, SMG1002-2S will not support the different VOIP protocols at same time, so when setting the protocol and number, users only need to set the parameters consistent with the softswitch’s protocol. The following two...

  • Page 6: Mgcp Protocol And Number Setting

    For example, the softswitch assigns 32 user nodes to the device "weych". The node ID of each user is "aaln / 01-aaln / 2". The MGCP configuration of the SMG1002-2S is shown in the following figure. The local domain name is set to "weych" The node prefix sets "aaln /" with the same 32 user nodes.

  • Page 7: Operation Test

    And then check the registration status of each port in “Number Configuration”, the status of the port is "registered" as soon as the registration succeeds. And connect The SMG1002-2S Port1-2 to telephone for dial test, test SMG1002-2S the caller and the called and other business conditions.
