Summary of Contents for Allsteel CONCENSYS CAPE

  • Page 1 MODEL: CAPE 2210 Second Avenue Muscatine, IA 52761-5257 31530 52006 IMPORTANT ® CONCENSYS INSTALLATION INSTRUCTIONS INSIDE ENGLISH VERSION POUR DES INSTRUCTIONS EN FRANCAIS, APPELER LE 800-822-7653 PARA INSTRUCCIONES EN ESPANOL, 70-0010 LLAME AL 800-822-7653 06/07/11...
  • Page 3 Concensys ® SYSTEMS GUIDELINES - PANELS Illustration 1 Read all instructions and review illustrations before installing. FOR ADEQUATE STABILITY of the Allsteel Company’s Concensys ® panel freestanding wall par- titions, one of two methods of stabilization must be adhered to: METHOD 1.
  • Page 4 Concensys ® SYSTEMS GUIDELINES - OVERHEAD STORAGE UNITS Illustration 1 Read all instructions and review illustrations before installing. Overhead Refer to Illustration 1. Units must be suspended on storage unit panels of a corresponding width, or suspended across two panels with a combined width equal to the storage unit width.
  • Page 5 C o n c e n s y s ® PANEL CONNECTORS WARNING Failure to install product as instructed, use of hardware other than that which is provided with the prod- uct, or failure to comply with all instructions can result in product failure and/or personal injury and/or property damage.
  • Page 6 C o n c e n s y s ® PANEL CONNECTORS Illustration 2. Top Cap Installation: Illustration 2a. Cableway Top Cap: Illustration 2b. Low Profile Top Cap: " long flat head undercut Transition piece self-threading screw Transition piece Cableway cap Top cap Cableway base...
  • Page 7 C o n c e n s y s ® PANEL CONNECTORS Illustration 4. END Connector Kit: Illustration 4a. Cableway Option: Cableway cap " long flat head undercut self-threading screw 1" long round head screw END transition Cableway base " long oval head countersunk screw END top bracket Vertical...
  • Page 8 C o n c e n s y s ® PANEL CONNECTORS Illustration 5. Wall Connector Kit: Illustration 5A. Mark Wall Connector Location onto Wall: 1. Place wall connector onto end of panel and position panel/wall connector against wall at location of wall connection.
  • Page 9 C o n c e n s y s ® PANEL CONNECTORS Illustration 5. Wall Connector Kit (cont): Illustration 5B. Direct to Wall Connection (cont): Wall connector Panel 5. Install transition piece onto end of panel facing wall. 6. Position panel into wall connector. 7.
  • Page 10 C o n c e n s y s ® PANEL CONNECTORS Illustration 5. Wall Connector Kit (cont): Illustration 5C. Offset Wall Connection (cont): Wall connector 5. Install transition piece onto end of panel Notch facing wall. 6. Position panel next to wall connector brackets.
  • Page 11 C o n c e n s y s ® PANEL CONNECTORS Illustration 6. Variable Height Connection: Illustration 6a. Panel Connection: Illustration 6b. Variable Height Bracket: " oval head countersunk screw long Variable height bracket Top bracket (For low-profile top cap option, connect transition piece and end transition cap.
  • Page 13 Concensys Concensys PANEL DOOR PANEL DOOR ® ® Illustration 1. Connect Door Panel to 82" High Panels (Door is Factory Assembled with a Right-Hand Orientation): Install door panel between two 82" Factory Assembled as Right-Hand high panels with standard panel ®...
  • Page 14 Concensys Concensys PANEL DOOR PANEL DOOR ® ® Illustration 3. Connect Door Panel to Wall Connector Kit: 1. Refer to Concensys ® Panel Connectors Installation Instructions to install 82" high wall connector kit. Do not install transition piece shipped with wall connector kit. 2.
  • Page 15 Concensys Concensys COUNTERTOPS AND WOOD SHELVES COUNTERTOPS AND WOOD SHELVES ® ® Countertops (Models with a RL, RH, or RS Illustration 1 prefix are routed at one end to fit at a vari- able height connection): • Insert support brackets and position as defined in Illustration 1.
  • Page 17 Concensys ® OVERHEAD STORAGE UNITS Illustration 1. Attach Overhead Storage Unit: Overhead End panel storage unit hooks Retaining clip Panel slots Installation (shelf and cabinet installation is the same): 1. Attach overhead storage unit to panel by inserting end panel hooks into panel slots. 2.
  • Page 18 Concensys OVERHEAD STORAGE UNITS ® Illustration 3. Overhead Shelf Unit Ganging (at seam of two inline overhead shelf units): Overhead shelf unit Screw Screw Ganging bracket Ganging Overhead bracket shelf unit Overhead shelf unit bottom flange 1. Hook ganging bracket over bottom flange of each overhead shelf unit. 2.
  • Page 19 Concensys ® ® PENINSULA / D-TOP / QUARTER-ROUND Illustration 1. Support Column Attachment: Attach support column to worksurface with four machine screws (from hardware pack) Threaded insert Threaded insert D-top Peninsula Lay worksurface upside down onto cardboard or a carpeted surface Illustration 2.
  • Page 20 Concensys ® ® PENINSULA / D-TOP / QUARTER-ROUND Illustration 2. Peninsula Installation (cont): Illustration 2b. Attachment to a Worksurface: Primary worksurface Attach flat bracket to primary worksurface and peninsula worksurface with twelve Attach each tie bracket (one per side (six per worksurface) wood screws (from of peninsula) with four flathead screws hardware pack) (from hardware pack)
  • Page 21 Concensys ® WORKSURFACE SUPPORTS Illustration 1. General Arrangement: Worksurface-to-panel support bracket (see Illustration 5) Center support bracket (see Flat bracket (see Illustration 8) Illustration 4) Corner support bracket (see Illustration 9) Support leg (see Illustration 3) Worksurface bracket kit (see Illustration 6) Cantilever support bracket (see Illustration 7)
  • Page 22 Concensys ® WORKSURFACE SUPPORTS Illustration 2. Full End Panel Support: Illustration 2a. Assemble Full End Support Panel: Step 1. Install machine screws through worksurface attachment bracket and into full end panel. Step 2. Install glides at bottom end of end panel. Left-Hand Application Right-Hand Application Illustration 2b.
  • Page 23 Concensys ® WORKSURFACE SUPPORTS Illustration 3. Support Leg: Assembly: 1. Assemble support leg, panel attachment bracket, and flat bracket in a configuration where the leg is under the largest worksurface. 2. Right-hand configuration is shown. Attach panel attachment bracket to opposite side of support leg for a left-hand configuration.
  • Page 24 Concensys ® WORKSURFACE SUPPORTS Illustration 4. Center Support Bracket: Note: Use center support bracket with worksurfaces longer Center support than 62 ". bracket (insert in 1. Install center support bracket onto panel. left-hand side of Install at panel connection) 2. Position and attach worksurface with wood screws. "...
  • Page 25 Concensys ® WORKSURFACE SUPPORTS Illustration 7. Cantilever Support Bracket: Illustration 7a. Preassemble Cantilever Support Bracket: Single-Sided Position mounting Application angle with slotted holes toward top 24" deep right-hand application (align mounting angle with rear notch) Machine screw Mounting angle Use round holes for ®...
  • Page 26 Concensys ® WORKSURFACE SUPPORTS Illustration 7. Cantilever Support Bracket (cont): Illustration 7b. Hang Cantilever Bracket onto Panels: • Drive bracket down with a rubber mallet to ensure bracket is firmly seated into panel slots. • Tie plate can be attached to adjacent worksurfaces to ensure alignment of Tie plate worksurfaces at the leading edge...
  • Page 27 Flexconnect ELECTRICAL SYSTEM (8-wire) WARNING Connection to a power source, by a licensed electrician, and quantity of receptacles used for a given cir- cuit must be in compliance with all national and local electrical codes. Connect a maximum of 13 recep- tacles (12 in Canada, and fewer in certain U.S.
  • Page 28 Flexconnect ELECTRICAL SYSTEM (8-wire) To facilitate ease of configuration of electrical components: • All Series – At least one power harness should be used at a Tee connection, when all 3 panels are powered. • All Series – At least two power harnesses should be used at a Cross connection, when all 4 panels are powered. •...
  • Page 29 Flexconnect ELECTRICAL SYSTEM (8-wire) ® CAUTION Terrace Series • The interior of panels is NOT to be used for routing electrical cords or extension cords. DO NOT rout cords through panel junctions. • Belt rail tiles must be hinge-mounted on both sides of panel when receptacles outlets are concealed within the beltline area.
  • Page 30 Flexconnect ELECTRICAL SYSTEM (8-wire) CAUTION • The interior of panels is NOT to be used for routing electrical cords or extension cords. DO NOT rout cords through panel junctions. Illustration 10. Stride Panel Beltline Area Electrical Illustration 11. Stride Beltline to Baserail Electrical Installation: Connection: Power...
  • Page 31 Flexconnect ELECTRICAL SYSTEM (8-wire) Illustration 14. Base or Ceiling Side In-Feed Installation: All Series WARNING Improperly installed electrical components can fail resulting in personal injury and/or property damage. Connection of the in-feed device to the power source should be performed by a licensed electrician in com- pliance with all national and local electrical codes.
  • Page 32 Flexconnect ELECTRICAL SYSTEM (8-wire) Illustration 15. Ceiling In-Feed Installation into Baserail Area: 8000 ® Series Plug into power block Note: For information regard- Ceiling in-feed cable 8719(12/18) - ing installation of power Power pole can be installed: poles, refer Into top of ELL/TEE/CROSS appropriate panel panel junctions where all panels...
  • Page 33 Concensys ® INTEGRATED POWER POLE Illustration 1 Illustration 2 Replace top bracket (90°, tee, or cross) with end brackets Remove power pole cover, loosen screw, extend bracket downward aligning with the appropriate notch, and retighten screw Illustration 3 – with cableway panels, align as shown –...
  • Page 34 Concensys ® INTEGRATED POWER POLE WARNING Connection to the power source should be performed by a licensed electrician in compliance with all national and local electrical codes. Failure to observe this warning could result in a fire. Illustration 6 Connect to building power source, by a licensed electrician, in compliance with national and local electrical codes Detail 1 Connect the male terminal end of the...
  • Page 35 Concensys PERMANENT WALL HANGER KIT ® • Customers must provide attachment hardware. Either; 1. #10 screws with metal “Molly” or “Toggle” type fasteners of an appropriate size for " (or thicker) drywall, mounted into drilled holes, or 2. #10 wood screws 2" long (minimum) for attachment directly into wood studs. WARNING An improperly installed permanent wall hanger kit and attached components can fail and/or fall resulting in severe injury to yourself or others.
  • Page 36 Concensys PERMANENT WALL HANGER KIT ® To achieve proper modularity with the Concensys ® Panel System, position slotted standards in relation to wall partitions as shown. Refer to panel installation instructions for attachment of panels to a permanent wall. (Make panel attachment before mounting adjacent wall track.) Note: When wall tracks interact with panels, vertical...
  • Page 37 Cadence FREESTANDING DESK APPLICATIONS WARNING Failure to install product as instructed, use of hardware other than that which is provided with the prod- uct, or failure to comply with all instructions can result in personal injury. Illustration 1. Configure Full End Panel Support to a Left-Hand or Right-Hand Application: Machine screw Machine screw Attachment bracket...
  • Page 38 Cadence FREESTANDING DESK APPLICATIONS Illustration 2. Primary Desk with Modesty Panel: Full end panel support Modesty panel Worksurface 1st - Machine screw (three per full end panel support): Install into worksurface inserts. 3rd - Wood screws (three per modesty panel, at each end and at center location): Install through top flange of modesty...
  • Page 39 Cadence FREESTANDING DESK APPLICATIONS Illustration 3. Primary Desk with Gussets: Note: Dependent on user preference, cosmetic side (flat side) of gusset can face either front or rear edge of worksurface. Full end panel support Gusset - Position rear edge of gusset 1 "...
  • Page 40 Cadence FREESTANDING DESK APPLICATIONS Illustration 4. Bridge and Return Attachment: Illustration 4A. Attach Modesty Panel Bracket: Place primary desk upside down onto cardboard or a carpeted surface. On side of primary desk that bridge or return is to be attached, position modesty panel bracket against interior surface of full end panel support.
  • Page 41 Cadence FREESTANDING DESK APPLICATIONS Illustration 4. Bridge and Return Attachment (continued): Illustration 4B. Attach Return or Bridge to Primary Desk: Bridge Attachment: Use three sheet metal screws to attach bridge modesty panel to modesty panel bracket (attached to primary desk full end panel support). Repeat procedure at opposite end of modesty panel.
  • Page 42 Cadence FREESTANDING DESK APPLICATIONS Illustration 5. Support Leg: Note: Use desk support legs to: · Attach a bridge to a peninsula (refer to Illustration 6). · Attach a return or bridge to a corner desk (refer to Illustration 7). Support leg Flat bracket Machine screw Notch - Position at rear...
  • Page 43 Cadence FREESTANDING DESK APPLICATIONS Illustration 6. Attach a Return or Bridge to a Peninsula Worksurface Using a Support Leg: Position support leg under peninsula worksurface. Align flat bracket center line locating notch with front edge of peninsula worksurface and rear edge with modesty panel top flange.
  • Page 44 Cadence FREESTANDING DESK APPLICATIONS Illustration 7. Corner Desk: Assemble return desks using support legs under return desk side of worksurface. Use three sheet metal screws to attach a corner desk modesty panel to each support leg. Use six sheet metal screws to attach corner desk support leg to free ends of corner desk modesty panels. Position corner desk worksurface onto flat brackets.
  • Page 45 C C o o n n c c e e n n s s y y s s ® ® T T E E C C H H N N O O L L O O G G Y Y P P A A N N E E L L Models: 991XXXX (porting on NOTE one side, as depicted)
  • Page 47 Concensys STACKING PANEL (GLASS) ® WARNING Improperly installed stacking panels can collapse resulting in severe injury. Follow these important safety tips: • Add no more than two stacking panels to any straight base panel. • Attach overhead storage components onto bottom stacking panels (connected to straight base panel) only. •...
  • Page 48 Concensys STACKING PANEL (FABRIC) ® WARNING Improperly installed stacking panels can collapse resulting in severe injury. Follow these important safety tips: • Add no more than two stacking panels to any straight base panel. • Attach overhead storage components onto bottom stacking panels (connected to straight base panel) only. Before installing fabric stacking panel to base panel, fab- ric stacking panel must be disassembled (refer to Illustration 2):...
  • Page 49 Concensys STACKING PANEL (GLASS & FABRIC) ® WARNING Improperly installed stacking panels can collapse resulting in severe injury. Follow these important safety tips: • Add no more than two stacking panels to any straight base panel. • Attach overhead storage components onto bottom stacking panels (connected to straight base panel) only. Detail A Detail B Illustration 1...
  • Page 50 Concensys STACKING PANEL (GLASS & FABRIC) ® WARNING Improperly installed stacking panels can collapse resulting in severe injury. Follow these important safety tips: • Add no more than two stacking panels to any straight base panel. • Attach overhead storage components onto bottom stacking panels (connected to straight base panel) only. Overhead storage Refer to Illustration 4.
