Allsteel Optimize Installation Packet

Hide thumbs
Table of Contents

Advertisement

Quick Links

Allsteel Inc.
Muscatine, Iowa 52761-0071
www.allsteeloffice.com
PAPE-E
45162 25194
6
Pour des instructions en francais, appeler le 800-822-7653
Para instrucciones en espanol, llame al 800-822-7653
Optimize
Contents
System Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 1
Panel Connections And Trim Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pages 2–4
Stacking Panel Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5
Panel Wall Connector Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 6
8 Wire Electrical Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pages 7–10
Power Pole Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 11
Worksurface Supports Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pages 12–16
Countertops Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 17
Overhead Storage Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pages 18–21
Sliding Door Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 22–27
7
Installation Packet
Installation Packet
343-3512A (03/13)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Optimize and is the answer not in the manual?

Questions and answers

Related Manuals for Allsteel Optimize

Summary of Contents for Allsteel Optimize

  • Page 1 Installation Packet Optimize Installation Packet Contents Allsteel Inc. System Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 1 Muscatine, Iowa 52761-0071 Panel Connections and Trim Installation .
  • Page 2 Optimize System Guidelines Optimize Panel Systems Panel Specifications Definitions: PARENT PANEL RUN - Panels (or a single panel) configured in a straight line intended to divide space. It is usually longer than the panels used to stabilize it . RETURN PANELS - Panels attached to a parent run for the purpose of stabilizing it . Return panels may also have the effect of dividing space .
  • Page 3 Optimize Panel Connections and Trim Installation Illustration 1: Panel to Corner Connector 1. Align the panels into the configuration required. Locate notches in bottom of corner connector to the glide tower. 2. Lift the corner connector post and slide the notches onto the tab of each glide tower.
  • Page 4 Optimize Panel Connections and Trim Installation Illustration 3: Variable Height Connections Illustration 4: Kickplate Panel to Corner Connector Post: 1 . Attach the bottom of the corner connector post to the glide tower tab on the panel . 2 . Attach VH bracket to the panel by inserting the tabs into the vertical tube and securing with two (F2) screws .
  • Page 5 Optimize Panel Connections and Trim Installation Illustration 7: Variable Height Panel to Corner Illustration 8: Inline Variable Height Panel Trim Connector Trim 1 . Install the top cap on the lower panel . 2 . Install the plastic end trim clips into the slotted steel tube with the screws (F3) provided .
  • Page 6 Optimize Stacking Panel Assembly Illustration 1: Optimize Panel System Stacking Panel Stacking Panel Warning • Add no more than one stacking panel to any base panel. • A severe impact or drop may cause immediate breakage or enough damage so that a glazed panel breaks later for no apparent reason .
  • Page 7 Optimize Panel Wall Connector Installation Illustration 1: Optimize Panel Wall Connector NOTE: Customer provides appropriate attachment hardware - wood screws into studs (2-1/2" long minimum), or molly-type fasteners into dry wall . Holes in wall connector are provided for #8 screws .
  • Page 8 Optimize 8 Wire Electrical Installation WARNiNG Connection to a power source, by a licensed electrician, and quantity of receptacles used for a given circuit must be in compliance with all national and local electrical codes. Connect a maximum of 13 receptacles (12 in Canada, and fewer in certain U.S.
  • Page 9 Optimize 8 Wire Electrical Installation To facilitate ease of configuration of electrical components: • At least one power harness should be used at a Tee connection, when all 3 panels are powered . • At least two power harnesses should be used at a Cross connection, when all 4 panels are powered .
  • Page 10 Optimize 8 Wire Electrical Installation Illustration 6. Base or Ceiling Side In-Feed Installation WARNiNG Improperly installed electrical components can fail resulting in personal injury and/or property damage. Connection of the in-feed device to the power source should be performed by a licensed electrician in compliance with all national and local electrical codes.
  • Page 11 Optimize 8 Wire Electrical Installation Note: For information regarding installation of power poles, refer to the appropriate panel series Power Pole Installation Instructions . Illustration 7: Ceiling In-Feed Installation into Baserail Area using Integrated Power Pole (870071) Ceiling in-feed cable 8719(12/18) - Position power pole into top of 90°, Tee, or...
  • Page 12 Optimize Power Pole Installation Illustration 1: Optimize Panel Power Pole Warning • Connection to the power source should be performed by a licensed electrician in compliance with all national and local electric codes. Failure to observe this warning could result in a fire.
  • Page 13 Optimize Worksurface Supports Installation Illustration 1: Full End Panel Support Illustration 1a: Assemble Full End Support Panel Step 1 - Install machine screws Step 1. Install machine screws through worksurface through worksurface attachment bracket attachment bracket and into full end panel.
  • Page 14 Optimize Worksurface Supports Installation Illustration 2: Support Leg Assembly: 1. Assemble support leg, panel attachment bracket, and flat bracket in a configuration where the leg is under the largest worksurface . 2. Right-hand configuration is shown. Attach panel attachment bracket to opposite side of support leg for a left-hand configuration.
  • Page 15 Optimize Worksurface Supports Installation Illustration 3: Center Support Bracket Note: Use center support bracket with worksurfaces longer Center support than 62¼" . bracket (insert Install at 27¾" Step 1 - Install center support bracket onto panel . in left-hand for a 29½" high Step 2 - Position and attach worksurface with wood screws .
  • Page 16 Optimize Worksurface Supports Installation Illustration 6: Hang Cantilever Bracket onto Panels Install at 27¾" for a 29½" high workspace Step 1 - Tilt the front of the cantilever bracket up and insert the top hook into desired slot of panel frame .
  • Page 17 Optimize Worksurface Supports Installation Illustration 9: Support Column (use with peninsula and D-shaped worksurfaces) Leveling glides Rear edge • Install support column so it is centered in the radius end of the peninsula . Support Verify the Column measurements are equal from...
  • Page 18 Optimize Countertops Installation • Countertops brackets marked ST will not work on 42" high panels. Use brackets marked 42 for 42" high panels. • Insert support brackets and position as defined in Illustration 1. • Position countertops and insert screws as defined in Illustration 2.
  • Page 19 Optimize Overhead Storage Installation Terrace DNA Installation Packet Illustration 46 . Overhead Shelf unit: Refer to Page 1 for Overhead Storage Guidelines Illustration 47a. Attach Overhead Shelf Unit: Illustration 1: Attach Overhead Shelf Unit Illustration 46a . Attach Overhead Shelf unit:...
  • Page 20 Optimize Overhead Storage Installation Terrace DNA Installation Packet Illustration 3: Overhead Shelf Unit Ganging (at seam of two inline overhead shelf units) Illustration 48 . Overhead Shelf unit Ganging (at seam of two inline overhead shelf units): Installed overhead shelf unit...
  • Page 21 Terrace DNA Installation Packet Optimize Overhead Storage Installation Illustration 49 . 15” h Overhead Storage Cabinet Installation: Illustration 4: 15" H Overhead Storage Cabinet Installation Illustration 4a: Attach 15" H Overhead Mounting Brackets to Panel System Illustration 49a . Attach 15” h Overhead Mounting Brackets to Panel System: 15”...
  • Page 22 Optimize Overhead Storage Installation Terrace DNA Installation Packet Illustration 49 . 15” h Overhead Storage Cabinet Installation: Illustration 4c: Position Overhead Storage Cabinet onto 15" H Overhead Mounting Brackets Illustration 49c . Position Overhead Storage Cabinet onto 15” h Overhead Mounting Brackets: 15”...
  • Page 23 Optimize Sliding Door Installation Illustration 1: Hook Plate Installation Hook plate - at panel run opening, measure up from floor and locate a Panel frame panel slot (bottom edge of slot) between dimensions as defined in Panel frame Table 1 . Insert bottom tab of hook plate into panel slot .
  • Page 24 Panel Concensys X=58- " X=71- " Terrace 3 .4 X=62" X=75" Terrace 2 .6 X=62" X=75" Table 3 (Stride, Terrace, DNA and Optimize) 50" Tall 65" Tall 80" Tall Panel Panel Panel X=41- " X=56- " X=71- " Table 4 (Align) 68"...
  • Page 25 Optimize Sliding Door Installation Illustration 5: Attach Top Rail Assembly Panel frame Hook Top rail assembly - insert top rail Panel frame assembly hooks into panel slots directly below anti-dislodgement Hook brackets . Top rail assembly brackets sit overtop anti-dislodgement brackets .
  • Page 26 Optimize Sliding Door Installation Illustration 7: Install Rear Door Stop and Attach Sliding Door to Top Track Assembly important - install rear door stop before Upper track attaching sliding door to upper door track Upper track assembly blade Sliding door - insert door upper track...
  • Page 27 Optimize Sliding Door Installation Illustration 8: Attach Sliding Door to Bottom Track Assembly Upper track assembly Panel frame Panel frame Lower track blade Sliding door - slide door along upper track assembly until door lower track blade feeds into bottom track...
  • Page 28 Optimize Sliding Door Installation Illustration 10: Install Sliding Door Handle Step 1 - Clean the plastic surface with a cleaning solvent (Glass Cleaner) . Step 2 - Wipe surface dry . Panel frame Step 3 - Remove tape backer and apply the handle to the plastic insert surface .
