Park
Installation Instructions
Index
Kit of Parts . . . . . . . . . . . . . . . . . . . . . 2
Noteables . . . . . . . . . . . . . . . . . . . . . . 2
Assembly . . . . . . . . . . . . . . . . . . . . . . 3
Worksurface Attachment . . . . . . . . . . . . 3
Electrical Attachment . . . . . . . . . . . . . . 4
Layered Conference Table, NALCF
Kit of Parts . . . . . . . . . . . . . . . . . . . . . 4
Noteables . . . . . . . . . . . . . . . . . . . . . . 4
Assembly. . . . . . . . . . . . . . . . . . . . . . . 5
Worksurface Attachment . . . . . . . . . . . . . 6
Electrical Attachment . . . . . . . . . . . . . 6
Kit of Parts. . . . . . . . . . . . . . . . . . . . . 7
Noteables. . . . . . . . . . . . . . . . . . . . . . 7
Assembly. . . . . . . . . . . . . . . . . . . . . . 7
Worksurface Attachment . . . . . . . . . . . . 8
Electrical Attachment . . . . . . . . . . . . . 8
Fastener Chart . . . . . . . . . . . . . . . . . . . . . . . 9
Page 1 of 9
Allsteel Inc.
Muscatine, Iowa 52761-0071
www.allsteeloffice.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Allsteel Park NA96RCF
Summary of Contents for Allsteel Park NA96RCF
-
Page 1: Table Of Contents
Electrical Attachment ... . . 8 Fastener Chart ..... . . 9 Allsteel Inc. Muscatine, Iowa 52761-0071 www.allsteeloffice.com... -
Page 2: 96" Racetrack Conference Table, Na96Rcf Kit Of Parts
Park Installation Packet W A R N I N G Failure to install product as instructed, use of hardware other than that which is provided, or failure to comply with instructions can result in product failure, personal injury, or property damage. Illustration 1a: Kit of Parts - 96”... -
Page 3: Assembly
Park Installation Packet Create Illustration 1c: 96” Racetrack Conference Table Assembly Step 1 - Complete Assembly while inverted on a clean, dry surface. Step 2 - On one side, slide the Top Crossbeams into the respective spots on the Short Legs and secure with 4 A screws. -
Page 4: Electrical Attachment
Park Installation Packet Illustration 1e: Electrical Attachment - Optional Step 1 - Determine locations for the slide mount on the underside of the worksurfaces. Reference images below for suggested locations. Step 2 - Install Slide Mount to the underside of the worksurface with given hardware and insert Minitap. Use provided clips to hold Nodes to bottom of worksurface. -
Page 5: Assembly
Park Installation Packet Create Illustration 2c: Layered Conference Table Assembly Step 1 - Complete Assembly while inverted on a clean, dry surface. Step 2 - Connect the Tall Leg and A-Frame with 4 A screws. Step 3 - Connect the Stretcher Bar and Top Angled Crossbeam to Short Legs using 8 A screws. Step 4 - Join the two subassemblies with 6 A screws. -
Page 6: Worksurface Attachment
Park Installation Packet Illustration 2d: Worksurface Attachment Step 1 -Place assembled base right side up and place round worksurface on top. Align pilot holes and use 6 B screws to attach worksurface. Make sure that the screws in the A-Frame are fully seated. Step 2- Place the pill shaped worksurface on the base. -
Page 7: 48" Freestanding Table, Na48Ss/Na48R Kit Of Parts
Park Installation Packet Create Illustration 3a: Kit of Parts - 48” Freestanding, NA48SS/NA48R Short Leg Stretcher Bar Illustration 3b: Noteables - Right hand and Left hand for some parts mportant When installed correctly, screws are countersunk. Reference image below. crew ppearance Short Leg Illustration 3c: 48”... -
Page 8: Worksurface Attachment
Park Installation Packet Illustration 3d: Worksurface Attachment Step 1 - Place worksurface topside down on a clean, dry surface. Place assembled base on top. Step 2 - Align pilot holes on the underside of the worksurface. Use 16 B screws to attach base to worksurface through attachment plate. -
Page 9: Fastener Chart
Park Installation Packet Create Illustration 4: Fastener Chart *** All screws printed to 1:1: scale *** 350-1675 50-2560 350-1675 Cable Management 350-1691 Strap (C) 3430408700 Page 9 of 9...
