MERGEINST
MERGE
Index
Base Positions Standard Leg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 1 thru 4
Power Caddy and Wire Manager . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 5
Lift and Release Post Leg Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 6
Adaptive Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 7 and 8
Height Adjustable X-base Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 9
Power Bay Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 10 thru 13
Power Wedge and Wire Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 14
Installation Packet
343-1830C
(10/11)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Allsteel MERGE
Summary of Contents for Allsteel MERGE
- Page 1 MERGE Installation Packet Index Base Positions Standard Leg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 1 thru 4 Allsteel Inc.
- Page 2 MERGE MERGE STANDARD LEG ASSEMBLY ACCESSORIES Illustration 1 . Base Positions 343-1830C PAGE 1 OF 14 (10/11)
- Page 3 MERGE MERGE STANDARD LEG ASSEMBLY ACCESSORIES Illustration 2 . Large T-bases Illustration 3 . Small and Medium T-bases 1. Align holes in top plate 1. Align holes in top plate with bosses in extrusion. with bosses in extrusion. 2. Using #3 Phillips driver, 2.
- Page 4 MERGE MERGE STANDARD LEG ASSEMBLY ACCESSORIES Illustration 5b . Powered X bases and Disc base Illustration 6a . Post Leg to worksurface (seated and standing height) 1. Align holes in top plate with (2) pilot holes in worksurface as 1. Align holes in base with bosses shown by dashed lines.
- Page 5 MERGE MERGE STANDARD LEG ASSEMBLY ACCESSORIES Illustration 6d . Counterweight kit option for Disc Illustration 6e . T base to worksurface base and Powered Disc base See Instructions for (6a). 1. Orient base ass- embly as shown. NOTE: If Stretcher Bar is required, complete instructions in 2.
- Page 6 • C. Snap Raceway cover into Raceway channel. Caddy into hole in worksurface. • B. If using a Merge Wire Manager, run cord along underside of worksurface, then down leg (T-base shown). • C. Hold cord against leg and snap Wire Manager onto leg (per instructions on page 14).
- Page 7 MERGE MERGE LIFT AND RELEASE POST LEG TABLE ACCESSORIES Illustration 1 . Assembly Instructions Levers See Illustration 6a on page 3. Levers Illustration 2 . Instructions for Use and Safety Mechanism Information Safety mechanism information: To raise table: - Lift and release legs contain - Squeeze levers on one end of the an integral safety mechanism.
- Page 8 MERGE MERGE ADAPTIVE TABLE ACCESSORIES Illustration 1 . Assembly Instructions 1. Ensure area is clear of any debris Required tools: that could scratch the worksurface. #3 Phillips Driver 2. Place the main and leaf worksurfaces face down on a clean surface. Orient...
- Page 9 MERGE MERGE ADAPTIVE TABLE ACCESSORIES Top view showing cable routing Illustration 3 . Assembly Instructions 9. Raise and lower the table three times to lubricate the cylinder. To raise, activate the pull handle, the table will automatically rise. To lower, push down in the middle of the table with the pull handle activated.
- Page 10 MERGE MERGE HEIGHT ADJUSTABLE X-BASE TABLE ACCESSORIES Top view showing cable routing Illustration 1 . Assembly Instructions 1. Check that area is clear of any debris that could Cable arc scratch the worksurface. must lie NOTE: The base assembly “within” the...
- Page 11 MERGE MERGE POWER BAY TABLE ACCESSORIES Illustration 1 . Power Bay Table Assembly Instructions Required Tools: • #3 Phillips Driver • #2 Phillips Driver • 1/4” Hex Head Driver DETAIL B • 7/16” Driver Rail/Trough • Clamps Assembly Stretcher Bar...
- Page 12 MERGE MERGE POWER BAY TABLE ACCESSORIES Illustration 3 . Power Bay Table Assembly Detail B IMPORTANT: Do 1/4 - 20 Tap Bolt not use impact gun 4. Position Leg/Stretcher Bar Assembly rightside ” Driver for installation of up. Set Rail/Trough Assembly on top of Leg/ screws into extrusion.
- Page 13 MERGE MERGE POWER BAY TABLE ACCESSORIES Veneer Matched Sets will be marked as shown Illustration 5 . Power Bay Table Assembly 8. Position the Slide Assembly so the bracket with the tab is located under the End Worksurface. Center the holes in the bracket with the screw inserts in the worksurface.
- Page 14 MERGE MERGE POWER BAY TABLE ACCESSORIES Illustration 6 . Power Bay Table Assembly 10. Adjust the End and Middle Worksurfaces so the outer edges DETAIL C are aligned and the spacing Slide between the worksurfaces is even. DETAIL D Assembly Make sure the Slide Assemblies are in the fully closed position.
- Page 15 4. Run Power Wedge cord through open area in Power Bay 1. Align Power Wedge with desired Power Wedge location vertical end wall. A Merge Wire Manager can be used to (two slots on Power Bay bottom, one hole in Power Bay neatly contain the Power Wedge cord against the table’s...
