SMC Networks XGTP31 50336 Series Operation Manual

Parallel seal type gate valve

Advertisement

Quick Links

IN21764
Doc. no. XG*-OMW0069
PRODUCT NAME
Parallel Seal Type Gate Valve
MODEL / SERIES / PRODUCT NUMBER
XGTP31*-50336-***
Thank you for purchasing SMC product. For appropriate operation of this
product, please read this operation manual thoroughly to understand. Also, refer
to the drawing, product information for structure and specification of this
product. Confirm operating environment is within operating specifications.
SMC Corporation
1
