Seven-Segment Display Has A "3; Downline Load Starts, Then Fails; Downline Load Does Not Start - Digital Networks DECserver 708 Installation Manual

Seven-Segment Display Has a "3"

If the seven-segment display has a "3" after power up, the DECserver 708 has a
downline loading problem. To isolate and diagnose the problem, do the following:
1)
Connect a terminal to the console port of the DECserver 708, then power up the
terminal.
2) Configure the terminal to operate with a speed of 9600 bits per second and a
character size of 8 bits (no parity). (Refer to the specific terminal user's guide if
you need help setting up the terminal parameters.)
3) Initialize the DECserver 708 by pressing Ctrl/P on your console terminal.
4) Read the message that appears on the terminal display.

Downline Load Starts, Then Fails

The following sequence of messages appears on the console terminal at various time
intervals:
Local –953– [IP] Attempting to locate load host, [ETHERNET]
Local –953– [MOP] Attempting to locate load host, [ISO8802]
Local –953– [MOP] Attempting to locate load host, [ETHERNET]
Local –955– [MOP] host xx-xx-xx-xx-xx-xx LOCATED [ETHERNET]
Local –956– [MOP] Requesting load from host xx-xx-xx-xx-xx-xx
Local –912– [MOP] Load failure, timeout
Problem
The host system failed to complete the downline load to the DECserver 708.
Correction
Copy the error message exactly as it appears on the console terminal display and notify
the network manager. For more information, refer to the Network Access Server
Problem Solving manual.

Downline Load Does Not Start

The following sequence of messages appears on the console terminal at various time
intervals:
Local –953– [IP] Attempting to locate load host, [ETHERNET]
Local –953– [MOP] Attempting to locate load host, [ISO8802]

Seven-Segment Display Has a "3"

What to Do If You Have Problems 6-11
