DECserver 90M+

Installation Guide

Part Number: IG-DCSRV-00
September 2003
This document describes how to install and troubleshoot the DECserver 90M+.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DECserver 90M+ and is the answer not in the manual?

Questions and answers

Related Manuals for Digital Networks DECserver 90M+

Summary of Contents for Digital Networks DECserver 90M+

  • Page 1: Installation Guide

    DECserver 90M+ Installation Guide Part Number: IG-DCSRV-00 September 2003 This document describes how to install and troubleshoot the DECserver 90M+.
  • Page 2 Digital Networks makes no representations that the use of its products in the manner described in this publication will not infringe on existing or future patent rights, nor do the descriptions contained in this publication imply the granting of licenses to make, use, or sell equipment or software in accordance with the description.
  • Page 3 NOTICES FCC Notice — Class A Computing Device: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 CE Notice — Class A Computing Device: Warning! This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. Achtung! Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb dieses Gerätes Rundfunkstörungen auftreten, in welchen Fällen der Benutzer für entsprechende Gegenmaßnahmen verantwortlich ist.

  • Page 5: Table Of Contents

    Preface Overview........................ -iii Purpose of This Guide ..................-iii Intended Audience .................... -iii Chapter 1 Overview Introduction......................1-1 In This Chapter ....................1-1 Chapter 2 Installation Overview....................... 2-1 Introduction...................... 2-1 In This Chapter ....................2-1 Standalone Installation..................2-2 Backplane Installation..................2-6 Booting From Flash RAM ................

  • Page 7: Overview

    Preface Overview This manual describes the procedures used to install and troubleshoot the DECserver 90M+. Purpose of This Guide This guide describes how to install the DECserver 90M+ hardware. It also provides problem-solving information and product specifications. Read through this guide completely to understand the features and capabilities. Intended Audience This guide is intended for the hardware installer.

  • Page 8: Structure Of This Guide

    Structure of This Guide This guide is organized as follows: Chapter/ Title Description Appendix Preface Preface Describes the use and audience for this document. Chapter 1 Overview Provides an overview of the DECserver 90M+ features. Chapter 2 Installation Describes selected methods of installing the DECserver 90M+.
  • Page 9 Conventions This document uses the following conventions. Convention Description Bold Type Indicates user input. special type This special type indicates system output or user input. Ctrl /X Hold down the Control key and simultaneously press the key specified by X. The DECserver displays this key combination as ^X.
  • Page 10 The following are used to call attention to important information throughout this document NOTE: Calls the reader’s attention to any item of information NOTE that may be of special importance. WARNING: Warns against an action that could result in the presence of an electrical hazard.

  • Page 11: Support Services

    To locate product-specific information, information about our other products, or product warranty information refer to our website: http://www.digitalnetworks.net/ To contact us by mail: Digital Networks 20 North Wentworth Ave Londonderry, NH 03053-7438 To contact us by phone: U.S. and Canada...
