Installing the Ethernet Cables and Devices

Installing the Standard Ethernet Cables and Devices

You can connect the DECserver 708 to the standard Ethernet/IEEE 802.3 network
(Figure 3–1) by connecting to:
•
A transceiver on a standard Ethernet coaxial cable for Digital Networks baseband
networks or other AUI interfaces.
Figure 3-1: Standard Ethernet Coaxial Cable Connection
Transceiver cable
Etherjack
DECserver 700
DECserver 700
3-4 Cabling the Site
Transceiver
Standard Ethernet
coaxial cable
DELNI
Transceiver cables
DECserver 700
LKG-5570-91I
