IInstalling Serial Cables and Devices on the DECserver
708
Use the following cables to connect EIA-232-D devices to the DECserver 708
9-pin D-connectors:
Table 3-1: Cables and Adapters for the DECserver 708
Cable and Adapters
H8585-AA Adapter
BN25G
BN24Q
H8575-A (EIA-423-A to EIA-232-
D) Adapter
•
Industry standard 9-pin female cable assemblies with 9-pin (male / female) or (
25-pin (male / female) D-connector as required.
•
To connect to RJ45 connectors use an H8585-AA adapter. Note: H8585-AA is a
cross adapter for transmitt & receive.
IInstalling Serial Cables and Devices on the DECserver 708
Description
Use this adapter to connect to the Serial port
9 -pin D-sub male connectors.
Use this cable to connect asynchronous,
also used to connect the 10BaseT to Ethernet.
Use this cable to connect serial port to serial
port, through H8585-AA connectors.
Use this adapter to connect to 25-pin D-sub
male connectors (for example: printers).
