Connector Pin Descriptions
Connector Pin Descriptions
This section describes the pins for the following DECserver 708 connectors:
•
Standard Ethernet/IEEE 802.3 transceiver interface
•
10BaseT Ethernet/IEEE 802.3 transceiver interface
•
DECserver 708 serial port connectors
Standard Ethernet
The standard Ethernet connector matches the signal specifications described in The
Ethernet: A Local Area Network: Data Link Layer and Physical Layer Specification.
