Table 1-4: DECserver 700 Connectors
Connector
Serial port connectors
(DECserver 708)
Standard Ethernet connector
10BaseT Ethernet connector
Power cord receptacle
Controls, Indicators, and Connectors
Description
These eight 9-pin male D-connectors connect
EIA-232-D devices to the DECserver 708.
This single 15-pin female D-connector
connects to a standard Ethernet/IEEE 802.3
local area network using a transceiver cable.
This single female RJ45 connector connects to
a 10BaseT Ethernet/IEEE 802.3 local area
network.
The DECserver 708 power cord plugs into this
receptacle.
