Linea Pro 7 User Manual
Assembling Your Linea Pro 7
1. Push the top cover forward, then up to insert your iOS device.
Top Cover
2. Connect the iOS device by firmly sliding it onto the Lightning™
connector.
3. Tilt the top cover down and slide it back until it clicks into place.
Note
:
To secure the unit, insert the two Torx screws on the back of the unit near the
top. The screw are provided with the Linea Pro 7.
Charging Your Linea Pro 7
The Linea Pro 7 uses a Lithium-ion rechargeable battery and supports
two modes for charging.
• Default Mode: Charging time is approximately 3
hours and 40 minutes.
• Slow Charging Mode: Charging time is
approximately 6 hours.
• If equipped with an encrypted magnetic stripe
reader, do not allow the battery to fully discharge.
• The unit disconnects from the iOS device if the
battery is depleted below 3.6V.
The Linea Pro 7 supports pass through charging to the iOS device. The
iOS device and Linea Pro 7 may be charged together via the USB Type-C
port or by placing it in a Linea Pro 7 Single or 5-Unit Charging Station.
Due to current charging limitations, the Linea Pro 7 should not be
charged via USB from a Windows computer or Apple OS connection.
• Connect the approved USB Type-C charging cable
into the USB port.
Reset Button
USB Sync/Charge Port
6
