Linea Pro 7 User Manual

Technical Specifications

Physical Dimensions
Processor 32-bit ARM™ Cortex™ - M3 MCU
Compatibility iPhone 6s/7/8/SE
Dimensions
1D/2D scanner:
157mm x 77 mm x 27 mm (6.2in x 3in x 1.1in)
(L) x (W) x (H)
Weight 148g (5.2 oz.) without iOS device
Port USB Type-C for charge/sync
Scan buttons (left and right)
Buttons Battery Status button
Reset button (pin-hole entry)
Connectivity
1D/2D laser, high-speed imager, which supports
Barcode scanner
all major 1D/2D barcodes
Rechargeable Li-ion Battery 3.7V /2400 mAh
Battery capacity
* Battery management via micro-controller
5V through USB Type-C cable
Power Supply
5V through single or 5 station charger
3-track bi-directional reader
Magnetic Stripe
Type: ISO 7810, 7811, 7813
Reader
1,000,000 magnetic card swipes
ISO/IEC 14443 Type-A/MIFARE:
» MIFARE MINI
» MIFARE CLASSIC-1K, MIFARE CLASSIC-4K
» MIFARE ULTRALIGHT, ULTRALIGHT-C
» MIFARE PLUS 2K/4K
» MIFARE DESFire card
» and others
(Optional) RFID
ISO/IEC 14443 Type - B:
reader
» Supports most cards
ISO 15693:
» Supports most cards
JIS X 6319-4:
» Compatible with FeliCa
ISO/IEC 18000-3 mode 3: NFC
Encryption/key
3DES, AES 128/256, DUKPT
management
(Optional) Bluetooth 2.0, Class 2 option, Serial Port Profile
Bluetooth (SPP)
Visual battery status: 4 LEDs
Indicators
Audio: electronmagnetic buzzer
Certifications
Apple® MFI / FCC
Environment
Operation: -10°C to +40°C (14°F to +104°F)
Temperature
Storage: -20°C to +50°C (-4°F to +122°F)
Relative Humidity Operation and Storage: 5%-90%

Linea Pro 7 Features

The Linea Pro 7 allows mobile employees to convert their iOS devices
into powerful solutions for the retail, warehousing, supply chain,
ticketing, and hospitality industries. The Linea Pro 7 includes 1D or 2D
barcode scanner, Bluetooth, and RFID.
Feature
1D/2D barcode Supports one-dimensional (1D) and two-
scanner dimensional (2D) barcode symbols, which can
be read in any direction (omni-directional).
The effective reading distance of the barcode
reader varies depending on the barcode size.
The barcode scanner is also capable of reading
barcodes on a LCD screen.
Magnetic stripe Built-in magnetic stripe reader incorporates a
reader (MSR) three-track, bi-directional magnetic read head. A
single swipe reads data from all three tracks.
RFID reader Built-in RFID tag/card reader with read/
write capability at 13.56 MHz. The RFID reader
incorporates several RFID formats, depending
on the model of your Linea Pro 7.
Indicators Four LEDs indicate battery status levels with an
electromagnetic buzzer.
Bluetooth Available Bluetooth 2.0 SPP compatibility, which
allows connection to a Bluetooth peripheral,
such as a printer.
Battery Status Press the Battery Status button to verify the
battery status.

Accessories

Visit our website at https://ipcmobile.com or contact your Infinite
Peripherals account representative for additional information about our
current and future product accessories.
Description
