SECTION 3 - MACHINE CONTROLS AND INDICATORS
3.6

PLATFORM CONTROL INDICATOR PANEL

1. Low Fuel (Ford DF 2.5L Only)
2. System Distress
3. Drive Orientation
4. Capacity Zone Indicator
3-16
1 2 3
14 13 12
5. Tilt Alarm/Warning
6. Creep
7. Footswitch
8. Glow Plug
4 5
11
10
9. Engine Emissions System Failure 13. Diesel Particulate Filter Indicator
10. Generator 14. Emissions Temperature
11. Platform Overload
12. Engine Error
6 7 8
9
