User Guide:
Version 4.4
Size: 7 x 9
DRAFT – FOR REVIEW ONLY
Installing AV8OR 3D in Your
Aircraft

Installing the INU and Antenna

The INU battery may be partially charged when you take it out of the box. The
INU will charge itself while plugged into the electrical system during the time the
aircraft is running.
Place the INU under your seat or in another suitable position. Although the Blue-
tooth capability between the INU and tablet PC makes it possible to place the INU
in various locations within the aircraft, it is important that the two devices be in
close proximity to each other (within 6 ft.).
When installing the INU, you need to consider how easy it is for you to reach the
power button. Other determining factors for placement are:
length of the power cords to your power source
length of the GPS antenna cable
distance of the INU from the tablet PC.
The INU should be positioned within the aircraft with its front panel facing out
toward the front of the aircraft. It must be securely attached in the most level and
stable position possible.
An optional mounting plate for the INU is also available. Visit
www.BendixKing.com or call for details.
The figure below shows the front panel view of the INU.
AV8OR 3D User Guide
Mode: Printing
5/23/06
2
13
