Relay Logic; Main Oven - Whirlpool IKEA IEL730C Technical Education

DIAGNOSTICS & TROUBLESHOOTING
FOR SERVICE TECHNICIAN'S USE ONLY
CODE WHAT IS IT?
F9E0 Miswired
Product is miswired.

Main Oven

Modes
Bake (Rapid Preheat) Preheat
Bake (Rapid Preheat) Steady State
Bake (Standard Preheat) Preheat
Bake (Standard Preheat) Steady State
Broil Preheat
Broil Steady State
Keep Warm Preheat
Keep Warm Steady State
Self Clean
Bread Proof Preheat
Bread Proof Steady State
Cvt Bake Preheat (True Convect)
Cvt Bake Steady State (True Convect)
Cvt Broil Preheat (True Convect)
Cvt Broil Steady State (True Convect)
Cvt Roast Preheat (True Convect)
Cvt Roast Steady State (True Convect)
Cvt Bake Preheat (Fan Convect)
n
4-8 Vesta Gas and Electric Slide-In Ranges
For Service Technician Use Only
WHEN CAN IT OCCUR? RECOMMENDED CORRECTIVE ACTION PROCEDURE
Anytime a miswired
product condition is
detected.

Relay Logic

Relays
Bake Broil Convect Convect
Element Fan
© © © ©
© © O X
© © © X
© © O X
O X O O
O © O O
© © O O
© © O O
© © O O
© © O O
© O O O
© © © X
© © © X
O © O X
O © O X
© © © X
© O © X
© © O X
1. Unplug range or disconnect power.
2. Check wires and connectors between main control (P6) and
power cord.
3. Check that the L1-L2-N wiring (pigtail) from the power outlet is
correctly connected to the range terminal block.
4. Replace all parts and panels before operating.
5.
Plug in range or reconnect power.
6.
Start a self-clean cycle and observe for 1 minute to ensure that
operation is normal. Enter the diagnostic mode to view the
"Faults" screen. Press START TIME or DELAY START to clear
each Fault code(s).
Modes
Cvt Bake Steady State (Fan Convect)
Cvt Broil Preheat (Fan Convect)
Cvt Broil Steady State (Fan Convect)
Cvt Roast Preheat (Fan Convect)
Cvt Roast Steady State (Fan Convect)
Legend
On
12
X
NOTE: Pre A/B represents two stages of preheat. SS represents steady state
(after reaching preheat temperature).
13
Relays
Bake Broil Convect
Element
© © O
O © O
O © O
© © O
© O O
Off On or Off
O ©
Convect
Fan
X
X
X
X
X
