Whirlpool IKEA IEL730C Technical Education page 43

Display Board Mounting
User Interface Mounting
User Interface Removed
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or
electrical shock.
e o ing the In nite S itches
1. Remove the Control Panel (see "Removing the Control
Panel section)
2. From the back of the control panel remove the infinite
switch electrical connections
Figure 30
Figure 31
. Remove the Control nob from the infinite switch
4. Locate and remove two mounting screws under the
control knob
. Pull infinite switch out from the back of the control panel
Figure 32
COMPONENT ACCESS
WARNING
Electrical Shock Hazard
Figure 34
Vesta Gas and Electric Slide-In Range
Figure 33
n
3-11
