FORWARD
This Job Aid, "30˝ Slide-In Gas and Electric Range," (Part No. W10748358), provides the technician with
information on the operation and service of the Self-Cleaning Slide-In Range. It is to be used as a training
Job Aid and Service Manual. For specific information on the model being serviced, refer to the "Use and
Care Guide," or "Tech Sheet" provided with the range.
The Wiring Diagrams and Strip Circuits used in this Job Aid are typical and should be used for training
purposes only. Always use the Wiring Diagram supplied with the product when servicing the unit.
GOALS AND OBJECTIVES
The goal of this Job Aid is to provide detailed information that will enable the service technician to properly
diagnose malfunctions and repair the Slide-In Self-Cleaning Range.
The objectives of this Job Aid are to:
• Understand and follow proper safety precautions.
• Successfully troubleshoot and diagnose malfunctions.
• Successfully perform necessary repairs.
• Successfully return the range to its proper operational status.
WHIRLPOOL CORPORATION assumes no responsibility for any repairs made on our
products by anyone other than authorized In-Home Service Professionals.
Copyright © 2014, Whirlpool Corporation, Benton Harbor, MI 49022
n
2
Vesta Gas and Electric Slide-In Ranges
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the IKEA IEL730C and is the answer not in the manual?
Questions and answers
HOW TO REPLACE WIRING FOR THE OVEN CONTROL PANEL BOARD
To replace the wiring for the Whirlpool oven control panel board (IKEA IEL730C), follow these steps:
1. Disconnect Power – Turn off the oven and unplug it to avoid electrical shock.
2. Remove the Control Panel – Follow the “Removing the Control Panel” section in the manual.
3. Access the Wiring – From the back of the control panel, locate the control board and its electrical connections.
4. Disconnect Wires – Carefully remove the wiring connections from the control board. Take a picture or note the wiring positions for reference.
5. Install the New Control Board – Position the replacement board correctly and reconnect the wires according to the original configuration.
6. Reassemble the Control Panel – Secure the control panel back in place.
7. Restore Power – Plug the oven back in and test the control panel to ensure proper operation.
Always replace all parts and panels before operating. Failure to do so can result in electrical shock or injury.
This answer is automatically generated
