Spectrum Industries 55515 Assembly Instructions

Assembly Instructions Assembly Instructions
Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt.
To report information regarding missing parts or damage, to purchase parts
or accessories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
(4) 056284
8-32 Wing nut
1
Assemble bar supports
1. The bars should be assembled with the tabs facing away from
each other as shown in Figure 1.
2. Loosen the (2) wingnuts slightly.
3. Repeat for the 2nd set of bars.
(1) 0147901
Tray
(2) 0142528
Bar support
(with threaded
weld studs)
(2) 0145039
Bar support B-side
(with slots)
Bar support
(with threaded weld studs)
Tab
8 " W
2 1 .
Accessory Shelf
55515
Hardware
(2) 042749
#8 x 1" PHSM
X 2
Bar support B-side
(with slots)
8-32 Wing nut
(2 per assembly)
1 5 .
8 " W
Tab
Figure 1
0191564R1 Page 1 of 2
