Altronix ReServV Video Surveillance UPS units are designed to provide power for 24VAC and/or 12VDC cam-
eras during normal or power outage conditions. True sine wave regulated AC outputs and/or regulated DC outputs.
Altronix
Model
Number
24VAC @ 4A (100VA) and 12VDC @ 2A
ReServ1V
24VAC @ 3.5A (85VA) and 12VDC @ 2A
ReServ2V
ReServ3V
Output:
• PTC protected outputs are rated @ 1A.
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries.
• Automatic switchover to stand-by battery
when AC fails.
Supervision:
• AC fail supervision (form "C" contacts).
• Low battery supervision (form "C" contacts).
Visual & Audio Indicators:
• AC/DC power LED indicators.
• Individual power output LED indicators.
• Low voltage input and Shutdown LED indicators.
• Audio AC Fail and Battery Fail indicator.
Stand-by Batteries
Two (2) 12VDC/7AH
Two (2) 12VDC/12AH
*When using 12AH batteries or larger a separate UL Listed battery enclosure must be installed.
Optional UL Listed battery enclosure must be mounted adjacent to the power supply via Class 1 wiring methods.
- 2 -
ReServV Series Video Surveillance UPS
Configuration Reference Chart:
Output/Supply
Current (A)
24VAC @ 4A (100VA)
24VAC @ 3.5A (85VA)
12VDC @ 8A
Stand-by Specifications:
ReServ1V - 4A (100VA) load at 24VAC and 2A load at 12VDC max.
Overview:
Ambient
Temperature
-33ºC to 30ºC
-33ºC to 42ºC
-33ºC to 30ºC
-33ºC to 42ºC
-33ºC to 42ºC
Specifications:
Additional Features:
• True sine wave regulated AC outputs
(ReServ1V & ReServ2V).
Regulated DC outputs (ReServ1V & ReServ3V).
• Unit maintains camera synchronization.
• Ease of installation saves time and
eliminates costly labor.
Enclosure Dimensions (H x W x D approximate):
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.6mm)
• Enclosure accommodates up to
two (2) 12VDC/7AH batteries.
ReServ2V - 4A (100VA) max. load at 24VAC
ReServ3V - 8A (100VA) max. load at 12VDC
45 minutes
90 minutes
PTC
Protected
Auto-
Input
Resettable
Rating
Outputs
230VAC,
16
50/60Hz, 2A
12
4
16
–
–
16
ReServV
