Specifications - Altronix ReServ1 Installation Manual

ReServ Video Surveillance UPS units are designed to provide power for 24VAC and/or 12VDC cameras during normal or
power outage conditions. True sine wave regulated AC outputs and/or regulated DC outputs.
ReServ Series Video Surveillance UPS Configuration Reference Chart:
Altronix
Model Output/Supply
Number Current (A)
24VAC @ 4A (100VA)
& 12VDC @ 2A
ReServ1
24VAC @ 3.5A (85VA)
& 12VDC @ 2A
24VAC @ 4A (100VA)
ReServ2
24VAC @ 3.5A (85VA)
ReServ3 12VDC @ 8A
Output:
• PTC protected power-limited outputs are rated @ 1A.
Battery Backup:
• Built-in charger for sealed lead acid or gel type batteries.
• Automatic switchover to stand-by battery when AC fails.
Supervision:
• AC fail supervision (form "C" contacts).
• Low battery supervision (form "C" contacts).
Visual & Audio Indicators:
• AC/DC power LED indicators.
• Individual power output LED indicators.
• Low voltage input and Shutdown LED indicators.
• Audio AC Fail and Battery Fail indicator.
ReServ1
Stand-by Batteries
Two (2) 12VDC/7AH
Two (2) 12VDC/12AH*
ReServ2
Stand-by Batteries
Two (2) 12VDC/7AH
Two (2) 12VDC/12AH*
ReServ3
Stand-by Batteries
Two (2) 12VDC/7AH
Two (2) 12VDC/12AH*
*When using 12AH batteries or larger a separate UL Listed battery enclosure must be installed. Optional UL Listed
battery enclosure must be mounted adjacent to the power supply via Class 1 wiring methods.
- 2 -
Overview:
Ambient Input
Temperature Rating
-33º to 30º C
115VAC
60Hz, 3.5A
-33º to 42º C
-33º to 30º C
115VAC
60Hz, 3.5A
-33º to 42º C
115VAC
-33º to 42º C
60Hz, 3.5A

Specifications:

Additional Features:
• True sine wave regulated AC outputs (ReServ1 &
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates costly labor.
Enclosure Dimensions (H x W x D approximate):
• Enclosure accommodates up to
Stand-by Specifications:
4A (100VA) load at 24VAC and 2A load at 12VDC max.
4A (100VA) max. load at 24VAC
8A (100VA) max. load at 12VDC
PTC
Protected
Power-
Limited
Outputs
16 12
16 16
16 ----
ReServ2). Regulated DC outputs (ReServ1 & ReServ3).
13.5" x 13" x 3.25" (342.9mm x 330.2mm x 82.6mm)
two (2) 12VDC/7AH batteries.
45 minutes
90 minutes
45 minutes
90 minutes
45 minutes
90 minutes
Agency UL Listings and
Listings File Numbers
UL File #
4
E329542
UL 60950-1
UL/CUL Listed
for
----
Information
Technology
Equipment.
16
ReServ
