Specifications - Altronix ReServ1WP Installation Manual

ReServWP Outdoor Video Surveillance UPS units are designed to provide power for 24VAC and/or 12VDC
cameras during normal or power outage conditions.
True sine wave regulated AC outputs and/or regulated DC outputs.
ReServWP Series Outdoor Video Surveillance UPS
Altronix
Model Output/Supply
Number Current (A)
24VAC @ 4A (100VA)
and 12VDC @ 2A
ReServ1WP
24VAC @ 3.5A (85VA)
and 12VDC @ 2A
24VAC @ 4A (100VA) -33ºC to 30ºC
ReServ2WP
24VAC @ 3.5A (85VA) -33ºC to 42ºC
ReServ3WP 12VDC @ 8A
Output:
• PTC protected power-limited outputs are rated @ 1A.
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries.
• Automatic switchover to stand-by battery
when AC fails.
Supervision:
• AC fail supervision (form "C" contacts).
• Low battery supervision (form "C" contacts).
Visual and Audio Indicators:
• AC/DC power LED indicators.
• Individual power output LED indicators.
• Low voltage input and Shutdown LED indicators.
• Audio AC Fail and Battery Fail indicator.
Stand-by Batteries
Two (2) 12VDC/7AH
Two (2) 12VDC/12AH
- 2 -
Overview:
Configuration Reference Chart:
Ambient
Temperature
-33ºC to 30ºC
-33ºC to 42ºC
115VAC,
-33ºC to 42ºC

Specifications:

Stand-by Specifications:
ReServ1WP - 4A (100VA) load at 24VAC and 2A load at 12VDC max.
ReServ2WP - 4A (100VA) max. load at 24VAC
ReServ3WP - 8A (100VA) max. load at 12VDC
Input
Rating
16 12
60Hz,
3.5A
16 16
–
16
Additional Features:
• True sine wave regulated AC outputs
(ReServ1WP and ReServ2WP).
Regulated DC outputs
(ReServ1WP and ReServ3WP).
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates
costly labor.
Enclosure Dimensions (H x W x D):
17.53" x 15.3" x 6.67"
(445.3mm x 388.6mm x 169.4mm).
• NEMA4 / IP66 Rated enclosure.
• Accommodates batteries:
- up to two (2) 12VDC/7AH batteries or
- up to two (2) 12VDC/12AH batteries.
45 minutes
90 minutes
Agency UL Listings and
Listings File Numbers
UL File # E329542
UL 60950-1
UL/CUL Listed
4
for Information
Technology
Equipment.
UL 60950-22
Information
–
Technology
Equipment - Safety -
Part 22: Equipment
16
to be Installed
Outdoors
ReServWP
