Fig. 2 - ReServ2V
Ground
Lug
Unswitched
230VAC
50Hz, 2A
power mains
- 6 -
CAUTION: Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteires according to the instructions.
12VDC Rechargeable Battery
(order separately)
Note: Two (2) 12VDC rechargeable batteries connected in series required.
P
N
1
2
3
4
5
6
7
8
24VAC Outputs
Supervised
12VDC Rechargeable Battery
Input
--- 24VDC +
LOW BATTERY
SHUTDOWN
9
10 11 12 13 14 15 16
(order separately)
ReServV
