ReServ5WP Video Surveillance UPS unit is designed to provide power for 24VAC and 12VDC cameras during
normal or power outage conditions. True sine wave regulated AC outputs and/or regulated DC outputs.
Agency Listings:
UL 60950-1 UL/CUL Listed for Information
Technology Equipment.
UL 60950-22 Information Technology Equipment -
Safety - Part 22: Equipment to be
Installed Outdoors
Input:
• 115VAC 60Hz, 3.5A.
Output:
• 4 individually PTC protected outputs
configured as follows:
- Two (2) Class 2 Rated PTC protected
24VAC outputs. PTCs rated @ 2.5A.
- Two (2) PTC protected 12VDC outputs.
PTCs rated @ 2.5A.
• Total supply current:
- 24VAC @ 4A max (96W).
- 12VDC @ 1A (12W).
Total output not to exceed 100W.

Battery Backup:

• Built-in charger for sealed lead acid or
gel type batteries.
This installation should be made by qualified service personnel and should conform to the National Electrical
Code and all local codes. This product contains no serviceable parts.
1. Remove back plate inside the enclosure by removing four (4) mounting screws and ground lug.
Do not discard hardware.
2. Mark and drill desired knockouts on the enclosure to facilitate wiring.
Note: It is required to use UL Listed outdoor rated conduit hubs with a minimum outdoor rating of NEMA4X.
3. Secure back plate and ground lug inside the enclosure with four (4) mounting screws (Fig. 1, pg. 4).
4. Mount unit in the desired location with the appropriate fasteners utilizing the holes on the flanges (pg. 8).
Secure enclosure to earth ground.
Note: This product needs to be secured to the building/pole before operation.
5. Connect AC power mains to the terminals marked [L] and [N] (Fig. 1, pg. 4).
Use 18 AWG or larger for all power connections (Battery, output) (Fig. 1, pg. 4).
Use 18 AWG to 22 AWG for power-limited circuits (AC Fail/Low Battery reporting) (Fig. 1, pg. 4).
Note: A readily accessible disconnect device shall be incorporated in the building installation wiring.
6. The LEDs on the power supply board will illuminate when AC power is present.
7. Measure output voltage before connecting cameras/devices to outputs.
This helps avoiding potential damage.
8. Connecting devices:
Connect 12VDC devices to the terminals marked [P 1-2, N 1-2] (Fig. 1, pg. 4).
Connect 24VAC devices to the terminals marked [15-16] (Fig. 1, pg. 4).
9. Connect batteries to the terminals marked [+ BAT –] (Fig. 1, pg. 4).
Use two (2) 12VDC batteries connected in series for 24VDC operation (battery leads included).
Use batteries - Casil CA12120 (12V/12AH) or UL recognized BAZR2 batteries of appropriate raing.
10. Connect appropriate signaling notification devices to AC FAIL & BAT FAIL (Fig. 1, pg. 4) supervisory
relay outputs.
11. The power LEDs on the unit for Outputs 1-2 and 15-16 will illuminate when AC power is present (Fig. 1, pg. 4).
Note: If any of the power LEDs are not illuminated, the cause may be due to the following:
a. AC mains and battery fail.
b. One (1) or more power output PTCs are tripped due to a short circuit or overload condition.
c. Unit damaged/defective.
- 2 -

Overview:

Specifications:

Battery Backup (cont'd):
• Automatic switchover to stand-by battery when
Supervision:
• AC fail and low battery supervision
Visual and Audio Indicators:
• AC/DC power LED indicators.
Visual Indicators:
• Individual power output LED indicators.
• Low voltage input and Shutdown LED indicators.
Additional Features:
• True sine wave regulated AC outputs and
• Unit maintains camera synchronization.
• Ease of installation saves time and eliminates
Enclosure Dimensions:
• NEMA4 / IP66 Rated enclosure accommodates up

Installation Instructions:

AC fails.
(form "C" contacts).
regulated DC outputs.
costly labor.
to two (2) 12VDC/12AH batteries.
17.53" x 15.3" x 6.67"
(445.3mm x 388.6mm x 169.4mm)
