3.3.3 Using The TCH002 Controller Hub

The TCH002 USB Controller Hub provides power distribution for up to six T-Cubes,
and requires only a single power connection (from a separate supply unit TPS006
supplied by Thorlabs). Further details are contained in handbook ha0146T T-Cube
Controller Hub, supplied with the unit.
DO NOT PLUG A POWERED UP T-CUBE INTO THE TCH002 USB
CONTROLLER HUB. Always ensure that all power is disconnected from
the laser source T-Cube AND the hub before the T-Cube is plugged into
the hub. Failure to observe this precaution will seriously damage the T-
Cube unit and could result in personal injury.

3.3.4 Supply Voltage and Current Requirements

The TLS001 is fitted with a 2.1mm DC connector. Thorlabs offers a compact, 5V
single way power supply (TPS101) for use with a single laser source cube.
Alternatively, an external regulated 5V power supply can be used.
Exceeding the power supply maximum voltage, or connecting a reverse
polarity voltage can cause permanent damage to the unit and could result
Supply
+5V
Warning
Warning
in personnal injury.
Table 3.1 Power Supply Ratings
Minimum Maximum
+4.9V
Max Operating Current
+5.1V
T-Cube Laser Source
500 mA
