Chapter 3

3.2 Mechanical Installation

3.2.1 Environmental Conditions

Operation outside the following environmental limits may adversely
Location
Maximum altitude
Temperature range
Maximum Humidity
To ensure reliable operation the unit should not be exposed to corrosive agents or
excessive moisture, heat or dust.
If the unit has been stored at a low temperature or in an environment of high humidity,
it must be allowed to reach ambient conditions before being powered up.

3.2.2 Mounting Options

The T-Cube Laser Source is shipped with a baseplate fitted, ready to be bolted to a
breadboard, optical table or similar surface.
If desired, the baseplate can be removed and the unit can be stood on rubber feet -
see Section 3.2.3.
For multiple cube systems, a USB controller hub (TCH002) is available - see Section
2.2. for further details. Full instructions on the fitting and use of the controller hub are
contained in handbook ha0146T T-Cube Controller Hub, shipped with the product.
When siting the unit, it should be positioned so as not to impede the
14
Warning
affect operator safety.
Indoor use only
2000 m
o o
5 C to 40 C
Less than 80% RH (non-condensing) at 31°C
Caution
operation of the control panel buttons.
HA0164T Rev F Feb 2018
