Step 6: Inserting Mounting Screw
Fix the Reader CB by sliding it backward such that mounting
slot of Reader and Mounting plate are in alignment. Insert
the mounting screw back in its position from bottom of the
device. Tighten the screw with 2 kgf-cm torque as shown in
figure.
Figure 13
13

Technical Specifications

Specification
Parameters
Credential Support
Card and Mobile credential over BLE
User Capacity
Depends on Master Device
Card storage
Depends on Master Device
Capacity
EM Prox, HID Prox, Mifare, Desfire, HID IClass
Type of Card
(CPM Module concept;Supports DOOR CPM Module)
Card Read Range
Reader Interface
RS- 232, RS- 485 and Wiegand
Type
Interface Support RS- 232 (10ft), RS- 485 (1200 meter)
Length Wiegand (150 meter)
5- 16 VDC @ max 150ma
Input Power
Buzzer
LED
Built in Bluetooth
Yes BLE (4.0 and above)
Tamper Detection
Operating
Temperature
Humidity 10% to 95% RH Non- condensing
Remarks
Upto 5cm
Yes
Yes (4 single color LEDs)
Yes
0°C to +50°C
14
