3. VoIP interface is optional. However to connect SIP Trunks/IP extensions, VoIP module must be present in
the ETERNITY NE. ETERNITY NE has inbuilt 8 IP Extensions. To connect another 8 IP extensions, you must
purchase the IP8 license.

Ports and Connectors

Port
24VDC- 2.5A (Max)
CO
SLT
Ethernet
Mobile 1 & Mobile 2

LED

LED Description
Power LED. Turns on when power is
PWR
supplied.
Status LED. Blinks to indicate health of
STS
the system.
2
Description
Connector for the power adapter.
Analog Trunk Port to connect analog trunk line.
Single Line Telephone (SLT) Port to connect any standard analog
telephone instrument and fax machine.
Ethernet Port can be used as:
• LAN interface to connect a Computer/LAN Switch.
• WAN interface to connect to IP network. As Ethernet WAN,
you can connect a Router/Modem or a LAN Switch.
Single SIM Mobile Ports to connect to the GSM/UMTS network.
Colour and Cadence
Continuous ON (Green)
1 second ON - 1 second OFF (Green), on
completion of boot-up.
