- Page 1 INSTALLATION & MAINTENANCE GUIDE Low Voltage Landscape Lighting ® Zero- Lead Wire System VariantPro Downlight ® AAL-1028-0-B-BZ Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
- Page 2 INSTALLATION & MAINTENANCE GUIDE Zero- Lead Wire System VariantPro Downlight ® AAL-1028-0-B-BZ Important Safety Instructions: Read Before Installation This luminaire is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 Package Contents A. (1) Fixture Body B. (1) Integrated Hub Top Product Dimensions There are two types of mounts that are sold separately for this fixture; the, Surface Mount and the Tripod Mount. Both must be used with this fixture in a downward orientation.
- Page 4 INSTALLATION & MAINTENANCE GUIDE Zero- Lead Wire System VariantPro Downlight ® AAL-1028-0-B-BZ Option1: Surface Mount Wire Connection Connectors Integrated Hub Top Fixture Wires Main Supply Wires Surface Mount Main Supply Wire Main Supply Wire Continuation Insert the main supply wire continuation (if needed) and the main supply wire up through the bottom of the surface mount and strip the ends of both sets of supply wires.
- Page 5 INSTALLATION & MAINTENANCE GUIDE Zero- Lead Wire System VariantPro Downlight ® AAL-1028-0-B-BZ Option 2: Tripod Mount Wire Connection Connectors Integrated Hub Top Fixture Wires Main Supply Wires Tripod Mount Main Supply Wire Main Supply Wire Continuation Insert the main supply wire continuation (if needed) and the main sup- ply wire up through the bottom of the tripod mount and strip the ends of both sets of supply wires.
- Page 6 INSTALLATION & MAINTENANCE GUIDE Zero- Lead Wire System VariantPro Downlight ® AAL-1028-0-B-BZ Bulb Installation Remove Glare Guard and Lens Loosen the lens and the set screw and remove the glare guard. Glare Guard Set Screw Lens Install Bulb Insert the bulb with the correct wattage and type marked on the Bulb luminaire label.
- Page 7 Install Lens and Glare Guard Thread the lens onto the fixture body and hand tighten. Then, place the glare guard onto Glare Guard the lens and secure with the previ- ously removed set screw. Set Screw Lens Fixture Body customersupport@amplighting.com • 813.978.3900 –7–...
- Page 8 Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2019, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m IS-AAL-1028-0-B-BZ-ver1.pdf...
