8.7

During operation

Installation and operating instructions Wilo-Control EC-L
Commissioning
‡
Configuration complete.
‡
Direction of rotation correct.
‡
Motor current monitoring set correctly.
1. Start Easy Actions menu: Turn the operating button 180°.
2. Select the pump for automatic mode: Turn the operating button until the menu
item is displayed:
– Pump 1: P1 Auto
– Pump 2: P2 Auto
– Pump 3: P3 Auto
3. Press the operating button.
⇒ Automatic mode is set for the selected pump. Alternatively, setting can be
performed in Menu 3.02 to 3.04.
▶ Automatic mode switched on. The pumps are switched on and off automatically,
depending on the fill levels.
Automatic mode after decommissioning
‡
The switchgear is closed.
‡
Checked configuration.
‡
Parameter input enabled: Menu 7.01 shows on.
1. Press the operating button for 3 s.
⇒ Menu 1.00 appears.
2. Turn the operating button until menu 3.00 appears
3. Press the operating button.
⇒ Menu 3.01 appears.
4. Press the operating button.
5. Change value to "on".
6. Press the operating button.
⇒ Value saved, pump enabled.
▶ Automatic mode switched on. The pumps are switched on and off automatically,
depending on the fill levels.
During operation make sure the following points are observed:
▪ Keep the switchgear closed and secure it against unauthorised opening.
▪ Switchgear attached in an overflow-proof manner (protection class IP54).
▪ Not exposed to direct sunlight.
▪ Ambient temperature between -30 °C and +50 °C.
The following items of information are shown on the main screen:
▪ Pump status:
– Number of registered pumps
– Pump activated/deactivated
– Pump On/Off
▪ Operation with standby pump
▪ Operating mode: fill or drain
▪ Current water level or switching state of the float switch
▪ Active field bus operation
Furthermore, the following information is available via menu 4:
1. Press the operating button for 3 s.
⇒ Menu 1.00 appears.
2. Turn the operating button until menu 4 appears.
3. Press the operating button.
▶ Menu 4.xx appears.
Current water level in m
