REMOVE COVERS FROM MD ARM

IF MOUNTING DIRECTLY TO WALL

ATTACH MD
WALL MOUNT
Page 1 of 3
MD ARM INSTALLATION INSTRUCTIONS
Using
a
Phillips
screwdriver, remove the four
screws from the upper cover,
exposing the cable channel.
WARNING - PINCH POINT:
Keep fi ngers away from
the inner arm area where
the gas spring is located.
The lower cover can also
be removed by lowering the
arm into the down position,
removing the screws and
sliding the cover forward off
of the arm.
Locate a stud in a
wall you intend to
mount your arm on.
OR
Mark the top hole,
drill 11/64 pilot hole
IF MOUNTING TO WALL TRACK
and insert an ICW
provided #14 screw
and tighten slightly.

ATTACH WALL PLATE TO TRACK

Using a level, mark
the 3 lower holes and
drill pilot holes, insert
the last three #14
screws and with the
mount level, tighten
all screws securely.
If you have any questions, please call 1-800-558-4435
head
Lift the wall
mount up to
the
bottom
of the TMD
track, or lower
over the top
of the track if
easier. Slide
the
clamp
plates into the
groove in the
TMD track.
Track
clamp
plates
MD ARM INSTALLATION INSTRUCTIONS - rev 04/22/14 pjm
Once
wall plate is
at the height
that
want it, use
the
key to lock it
into place by
Clamp
turning
screws
3
screws
to
clockwise.
the
you
/
hex
5
32
the
clamping
in
place
