TP-Link 24+2/24+2G User Manual page 23

TL-SF2226P+/TL-SL2226P+
you can see the interface as follows. For more details, please refer to help file.
7. MAC Aging Time
Dynamic forwarding table entries, which are made up of the source and destination MAC
address and their associated port numbers, are deleted from the table if they are not
accessed within the aging time. The aging time can be from 300 to 765 seconds.
Steps of Setting: Click main menu->Config->MAC Aging Time or click the MAC Aging
Time icon on the toolbar, then configure MAC Aging Time in the pop-up dialog.
8. Change IP
Click main menu->Config->Change IP, you will see the interface as follows.
The IP and Gateway before changed is current IP and Gateway of the switch. Through
this dialog, you can change the switch IP and Gateway. This operation will cause the
switch disconnect.
Remote Smart Switch User Guide
Figure 5-19
Figure 5-20
- 20 -
