Installation Guide

5/8-Port Gigabit Desktop Switch
LS105G/LS108G
Note:
For simplicity, we will take LS108G for example throughout this Guide.
Connection
Power Adapter
Router
WAN Port
LAN Port
LED Explanation
Power
On: Power on
Off: Power off or power supply is abnormal
Flashing: Power off or power supply is abnormal
Link/Act
Link/Act (Green)
On: Running at 10/100/1000Mbps
Off: No device is linked to the
corresponding port
Flashing: Transmitting/receiving data
LS108G
PC
Ethernet Ports (1-8)
PC
